ROHM BD9355MWV-E2

Manufacturer No:

BD9355MWV-E2

Manufacturer:

ROHM

Package:

Description:

260 Cel QUAD Specialized Voltage Regulator 2MHz 36 Terminations

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BD9355MWV-E2 information

ROHM BD9355MWV-E2 technical specifications, attributes, parameters and parts with similar specifications to ROHM BD9355MWV-E2.

Type
Parameter

Factory Lead Time
9 Weeks

Mount
Surface Mount

Packaging
Tape & Reel (TR)

Published
2011

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
36

ECCN Code
EAR99

Type
Integrated Circuit (IC)

Max Operating Temperature
85°C

Min Operating Temperature
-25°C

HTS Code
8542.39.00.01

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Terminal Pitch
0.4mm

Time@Peak Reflow Temperature-Max (s)
10

JESD-30 Code
S-XQCC-N36

Number of Outputs
7

Output Voltage
26V

Output Type
Adjustable

Operating Supply Voltage
5.5V

Input Voltage-Nom
3V

Output Current
2.2A

Min Input Voltage
1.5V

Control Mode
CURRENT-MODE

Max Input Voltage
5.5V

Control Technique
PULSE WIDTH MODULATION

Switcher Configuration
BOOST

Switching Frequency
2MHz

Length
5mm

Height Seated (Max)
1mm

Width
5mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for ROHM BD9355MWV-E2.

Datasheets:

rohm-bd9355mwve2-datasheets-6919.pdf

BD9355MWV-E2 Overview

Currently, it supports a total of 7 outputs. Currently available in Tape & Reel (TR) packages for shipping. Electronic components have 36 terminals. A Surface Mount is provided for mounting it on PCBs and other boards. A temperature lower than -25°Cis not suitable for the shunt regulator. There is no need to exceed 85°C in terms of temperature. In order to operate normally, a supply voltage of 5.5V is required. As of now, the external regulator should be producing 2.2Aas its output. There is a requirement for an input voltage greater than 1.5Vfor this alternator regulator. DC voltage regulators can operate at a frequency of 2MHz.

BD9355MWV-E2 Features

Supply voltage: 5.5V

BD9355MWV-E2 Applications

There are a lot of ROHM Semiconductor
BD9355MWV-E2 Specialized Voltage Regulators applications.

Copier/Printer
Set-Top Box
DDR Vooo and V? Voltage Generation
PC Dual Power Supply
Server DDR Power
Desktop Computer
Graphics Cards
Cell Phones
Wireless Modems
PCS Phones
