ONSEMI BD238S
ONSEMI BD238S

ONSEMI BD238S

Manufacturer No:

BD238S

Manufacturer:

ONSEMI

Package:

TO-225AA, TO-126-3

Description:

PNP 150°C TJ 100?A ICBO 1 Elements 3 Terminations SILICON PNP TO-225AA, TO-126-3 Bulk Through Hole

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BD238S information

ONSEMI BD238S technical specifications, attributes, parameters and parts with similar specifications to ONSEMI BD238S.

  • Type
  • Parameter
  • Mount
  • Through Hole
  • Mounting Type
  • Through Hole
  • Package / Case
  • TO-225AA, TO-126-3
  • Number of Pins
  • 3
  • Weight
  • 761mg
  • Transistor Element Material
  • SILICON
  • Operating Temperature
  • 150°C TJ
  • Packaging
  • Bulk
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 3
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin (Sn)
  • Subcategory
  • Other Transistors
  • Voltage - Rated DC
  • -80V
  • Max Power Dissipation
  • 25W
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Current Rating
  • -2A
  • Frequency
  • 3MHz
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • BD238
  • Qualification Status
  • Not Qualified
  • Element Configuration
  • Single
  • Power Dissipation
  • 25W
  • Transistor Application
  • SWITCHING
  • Gain Bandwidth Product
  • 3MHz
  • Polarity/Channel Type
  • PNP
  • Transistor Type
  • PNP
  • Collector Emitter Voltage (VCEO)
  • 80V
  • Max Collector Current
  • 2A
  • DC Current Gain (hFE) (Min) @ Ic, Vce
  • 25 @ 1A 2V
  • Current - Collector Cutoff (Max)
  • 100?A ICBO
  • Vce Saturation (Max) @ Ib, Ic
  • 600mV @ 100mA, 1A
  • Collector Emitter Breakdown Voltage
  • 80V
  • Transition Frequency
  • 3MHz
  • Collector Base Voltage (VCBO)
  • -100V
  • Emitter Base Voltage (VEBO)
  • -5V
  • hFE Min
  • 25
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ONSEMI BD238S.

Datasheets:

ReachStatement:

BD238S Overview


As explained above, DC current gain takes into account the rate at which the base current flows through the collector current; therefore, DC current gain for this device is 25 @ 1A 2V.In VCE saturation, Ic is at its maximum value (saturated), and the vce saturation (Max) is 600mV @ 100mA, 1A.The emitter base voltage can be kept at -5V for high efficiency.The current rating of this fuse is -2A, which means that transistor can carry an indefintransistore amount of current wtransistorhout deteriorating too much.The part has a transition frequency of 3MHz.Single BJT transistor is possible to have a collector current as low as 2A volts at Single BJT transistors maximum.

BD238S Features


the DC current gain for this device is 25 @ 1A 2V
the vce saturation(Max) is 600mV @ 100mA, 1A
the emitter base voltage is kept at -5V
the current rating of this device is -2A
a transition frequency of 3MHz


BD238S Applications


There are a lot of ON Semiconductor
BD238S applications of single BJT transistors.
