ROHM BA6287F-E2

Manufacturer No:

BA6287F-E2

Manufacturer:

ROHM

Package:

ROHS COMPLIANT, SOP-8

Description:

Description: Brush DC Motor Controller, 1A, BIPolar, PDSO8, ROHS COMPLIANT, SOP-8

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

BA6287F-E2 information

ROHM BA6287F-E2 technical specifications, attributes, parameters and parts with similar specifications to ROHM BA6287F-E2.

Type
Parameter

Pbfree Code
Yes

RoHS Status
RoHS Compliant

Part Life Cycle Code
Not Recommended

Ihs Manufacturer
ROHM CO LTD

Part Package Code
SOIC

Package Description
ROHS COMPLIANT, SOP-8

Pin Count
8

Reach Compliance Code
compliant

ECCN Code
EAR99

HTS Code
8542.39.00.01

Samacsys Manufacturer
ROHM Semiconductor

Analog IC - Other Type
BRUSH DC MOTOR CONTROLLER

JESD-30 Code
R-PDSO-G8

Length
5 mm

Number of Functions
1

Number of Terminals
8

Operating Temperature-Max
75 °C

Operating Temperature-Min
-20 °C

Output Current-Max
1 A

Package Body Material
PLASTIC/EPOXY

Package Code
SOP

Package Equivalence Code
SOP8,.25

Package Shape
RECTANGULAR

Package Style
SMALL OUTLINE

Qualification Status
Not Qualified

Seated Height-Max
1.71 mm

Supply Current-Max (Isup)
67 mA

Supply Voltage-Max (Vsup)
15 V

Supply Voltage-Min (Vsup)
4.5 V

Supply Voltage-Nom (Vsup)
9 V

Surface Mount
YES

Technology
BIPOLAR

Temperature Grade
COMMERCIAL EXTENDED

Terminal Form
GULL WING

Terminal Pitch
1.27 mm

Terminal Position
DUAL

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Width
4.4 mm

Download datasheets and manufacturer documentation for ROHM BA6287F-E2.

BA6287F-E2 Overview

The design includes a package of type [0].Drivers controllers is packaged wDrivers controllersh a 8-SOIC (0.173, 4.40mm Width) case.In most cases, it is recommended to mount the part at Surface Mount.I believe it would be suitable for the component connected to Media Player.A device with a voltage range of 4.5V~15V volts is available.The operating temperature ranges from -20°C~150°C TJto -20°C~150°C TJ.In this case, the motor type is Brushed DC.The part supports 8terminations.At a rate of [0], voltage can be applied to the load.Drivers controllers is important to note that this amplifier should be operated at the 9Vsetting.Surface Mountis the recommended mounting method.Ensure that the part output current remains at 1A.The device utilizes the IC BRUSH DC MOTOR CONTROLLERwhich is an analog IC.8pins are available on the device.The Motion Control Electronicsseries contains it.

BA6287F-E2 Features

Applications : Media Player
Load voltage across the chip 4.5V~15V

BA6287F-E2 Applications

There are a lot of ROHM Semiconductor
BA6287F-E2 motor drivers applications.

Dome
Dash
Footwell lighting
Indicator
Telltale lights
Infotainment backlighting
Tail lights
Turn signals
Brake lights
CHMSL (center high-mount stop lamps)
