Manufacturer No:

B6B-PH-SM4-TBT(LF)(SN)

Manufacturer:

JST

Package:

Description:

PH Series 1-Row Header Solder Copper Alloy Tape & Reel (TR) Surface Mount Tin Polyamide (PA6T), Nylon 6T 6-Position Board to Cable/Wire 0.260 6.60mm Height

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

B6B-PH-SM4-TBT(LF)(SN) information

JST B6B-PH-SM4-TBT(LF)(SN) technical specifications, attributes, parameters and parts with similar specifications to JST B6B-PH-SM4-TBT(LF)(SN).

  • Type
  • Parameter
  • Factory Lead Time
  • 18 Weeks
  • Contact Material
  • Copper Alloy
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Contact Shape
  • Square
  • Insulation Material
  • Polyamide (PA6T), Nylon 6T
  • Operating Temperature
  • -25°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • PH
  • Published
  • 2008
  • JESD-609 Code
  • e3
  • Feature
  • Pick and Place, Solder Retention
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • Header
  • Number of Positions
  • 6
  • Number of Rows
  • 1
  • Voltage - Rated
  • 100V
  • Additional Feature
  • LOW PROFILE
  • Fastening Type
  • Detent Lock
  • Contact Finish - Mating
  • Tin
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • Filter Feature
  • NO
  • Contact Type
  • Male Pin
  • Mixed Contacts
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 2A
  • Total Number of Contacts
  • 6
  • Terminal Pitch
  • 2mm
  • Insulation Height
  • 0.260 6.60mm
  • Style
  • Board to Cable/Wire
  • Number of Positions Loaded
  • All
  • Pitch - Mating
  • 0.079 2.00mm
  • Insulation Color
  • Natural
  • Shrouding
  • Shrouded - 4 Wall
  • Contact Length - Mating
  • 0.130 3.30mm
  • UL Flammability Code
  • 94V-0
  • Stack Height (Mating)
  • 8.6mm
  • Material Flammability Rating
  • UL94 V-0
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for JST B6B-PH-SM4-TBT(LF)(SN).

Datasheets:

B6B-PH-SM4-TBT(LF)(SN) Overview


Packaging for this item is Header.There is a mounting type of Surface Mount for this device.It is necessary to use a Tape & Reel (TR) case for packaging the product.This product is part of the PH Series.Moreover, there are a number of other features, including LOW PROFILE, to name just a few.In many ways, its Pick and Place, Solder Retention feature makes it more powerful.Surface Mount is used to mount the part.In this case, the device operates at -25°C~85°C Operating Temperature.

B6B-PH-SM4-TBT(LF)(SN) Features


PH series


B6B-PH-SM4-TBT(LF)(SN) Applications


There are a lot of JST Sales America Inc.
B6B-PH-SM4-TBT(LF)(SN) Rectangular Connectors applications.


  • Transportation
  • Embedded systems
  • Datacom
  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
