Microchip ATF22V10C-7JU

Manufacturer No:

ATF22V10C-7JU

Manufacturer:

Microchip

Package:

28-LCC (J-Lead)

Description:

ATF22V10C

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ATF22V10C-7JU information

Microchip ATF22V10C-7JU technical specifications, attributes, parameters and parts with similar specifications to Microchip ATF22V10C-7JU.

Type
Parameter

Power Options
STANDARD

Operating Voltage Min (V)
4.5

Operating Voltage Max (V)
5.5

Inputs and I/O Pins
22

Registers
10

Macrocells
10

tPD Min
5

Max Clock Freq
166

Temp# Range Min (deg C)
-55

Temp# Range Max (deg C)
125

Download datasheets and manufacturer documentation for Microchip ATF22V10C-7JU.

A high-performance electrically erasable CMOS programmable logic device (PLD) with proven Microchip electrically erasable flash memory. The device supports speeds down to 5ns and power dissipation as low as 10??A (typical). All speed ranges are specified over the full 5V ± 10% range for military and industrial applications and 5V ± 5 percent for commercial applications. Each of several low-power options can significantly reduce total system power and enhance system reliability.
