Microchip AT28C64B-15SU
Microchip AT28C64B-15SU

Microchip AT28C64B-15SU

Manufacturer No:

AT28C64B-15SU

Manufacturer:

Microchip

Package:

28-SOIC (0.295, 7.50mm Width)

Description:

5V 64Kbit (8Kbit x 8) Parallel EEPROM with Software Data Protection

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AT28C64B-15SU information

Microchip AT28C64B-15SU technical specifications, attributes, parameters and parts with similar specifications to Microchip AT28C64B-15SU.

  • Type
  • Parameter
  • Battery Backup
  • No
  • Density
  • 64 Kbit
  • Endurance
  • 10,000
  • Max. Clock Freq.
  • .
  • Operating Voltage Max (V)
  • 5.5
  • Operating Voltage Min (V)
  • 4.5
  • Page Size (Bytes)
  • 64
  • Write Protected
  • No
  • Data Retention
  • 10
  • Read Access Speed
  • 150ns

Download datasheets and manufacturer documentation for Microchip AT28C64B-15SU.

Miscellaneous:

Brochures:

Application Notes:

Supporting Collateral:

Data Sheets:

The Microchip AT28C64B is a high-performance 64Kbit Parallel EEPROM offering access times to 150ns with power dissipation of 220mW. Deselected, CMOS standby current is less than 100µA. Accessed like static RAM for the read or write cycle without external components, it contains a 64-byte page register to allow writing of up to 64 bytes simultaneously. Optional Software Data Protection mechanism guards against inadvertent writes; and an extra 64 bytes of EEPROM enables device identification or tracking.

    • 8 Kbits x 8 (64 Kbit)
    • 5V ±10% Supply
    • Parallel Interface
    • 150ns access time
    • Self-Timed Erase and Write Cycles (10 ms max)
    • Page Write and Byte Write
    • Data Polling for end of write detection
    • Low Power Consumption
    • Read / Write current 40 mA (Max)
    • Standby current TTL 2 mA (Max), CMOS 100 µA (Max)
    • Hardware Protection
    • Software Data Protect
    • More than 100,000 erase/write cycles
    • Data retention > 10 years
    • Temperature Ranges
    • Standard Temperature Range: -40°C to 85°C
    • Available in Green (Pb/Halide-free) Packaging Only
    • 32-lead, Plastic J-leaded Chip Carrier (PLCC)
    • 28-lead, 0.600" Wide, Plastic Dual Inline Package (PDIP)
    • 28-lead, 0.300" Wide, Plastic Gull Wing Small Outline (SOIC)
    • 28-lead, Plastic Thin Small Outline Package (TSOP)
