Manufacturer No:

AS196-307LF

Manufacturer:

SKYWORKS

Package:

16-VQFN Exposed Pad

Description:

GSM, ISM, PCS, WCDMA RF Type SPDT -40°C~85°C 300kHz~6GHz Isolation:30dB Insertion Loss:1.6dB Absorptive 50Ohm IIP3:46dBm 2.6V~5V

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AS196-307LF information

SKYWORKS AS196-307LF technical specifications, attributes, parameters and parts with similar specifications to SKYWORKS AS196-307LF.

  • Type
  • Parameter
  • Package / Case
  • 16-VQFN Exposed Pad
  • Surface Mount
  • YES
  • Mounting Feature
  • SURFACE MOUNT
  • Number of Pins
  • 16
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 2006
  • JESD-609 Code
  • e3
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 16
  • Terminal Finish
  • Matte Tin (Sn)
  • Subcategory
  • RF/Microwave Switches
  • Technology
  • GAAS
  • Voltage - Supply
  • 2.6V~5V
  • Number of Functions
  • 1
  • Construction
  • COMPONENT
  • Frequency
  • 6GHz
  • Operating Supply Voltage
  • 5V
  • Circuit
  • SPDT
  • Impedance
  • 50Ohm
  • Turn On Delay Time
  • 50 ns
  • Topology
  • Absorptive
  • Turn-Off Delay Time
  • 50 ns
  • Insertion Loss
  • 1.6dB
  • Isolation
  • 30dB
  • VSWR-Max
  • 1.6
  • Insertion Loss (dB)
  • 1.6 dB
  • RF Type
  • GSM, ISM, PCS, WCDMA
  • Input Power-Max (CW)
  • 30dBm
  • P1dB
  • 27dBm
  • IIP3
  • 46dBm
  • On Time-Nom
  • 0.05 ?s
  • 1dB Compression Point
  • 21 dBm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for SKYWORKS AS196-307LF.

Datasheets:

AS196-307LF Overview


optimized performance is achieved by utilizing the Tape & Reel (TR) package in this RF Switch.Throughout this RF Switch, there are 16 terminations.During RF Switch operation, the operating temperature should remain at -40°C~85°C.In terms of category, this RF light switch falls into the RF/Microwave Switches category.There are 16 pins used for high power RF switch operation.Input RF type GSM, ISM, PCS, WCDMA of the RF switch ic.It is possible to supply 2.6V~5V volts to the RF Switch.

AS196-307LF Features


Tape & Reel (TR) package
16 terminations
RF/Microwave Switches subcategory
16 pins
GSM, ISM, PCS, WCDMA RF Type


AS196-307LF Applications


There are a lot of Skyworks Solutions Inc.
AS196-307LF RF Switches applications.


  • Cellular/PCS Base Stations
  • ISM
  • Wireless Local Loop
  • Smartphones
  • Tablets
  • Mobile devices
  • Smart metering
  • Cellular infrastructures
  • LTE diversity applications
  • WCDMA diversity applications
