OSRAM AS1345A-BTDT-AD

Manufacturer No:

AS1345A-BTDT-AD

Manufacturer:

OSRAM

Package:

8-UFDFN

Description:

8-Pin DC DC Voltage Regulator 1 Outputs Tape & Reel (TR) 1A Switch 8-UFDFN

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AS1345A-BTDT-AD information

OSRAM AS1345A-BTDT-AD technical specifications, attributes, parameters and parts with similar specifications to OSRAM AS1345A-BTDT-AD.

Type
Parameter

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
8-UFDFN

Number of Pins
8

Operating Temperature
-40°C~85°C TA

Packaging
Tape & Reel (TR)

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Function
Step-Up

Number of Outputs
1

Voltage - Input (Max)
5V

Output Voltage
18V

Output Type
Adjustable

Max Output Current
40mA

Min Supply Voltage
2.9V

Output Configuration
Positive

Current - Output
1A Switch

Topology
Boost

Synchronous Rectifier
No

Voltage - Output (Max)
18V

Switching Frequency
10kHz

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for OSRAM AS1345A-BTDT-AD.

Datasheets:

ams-as1345abwlt15-datasheets-4378.pdf

AS1345A-BTDT-AD Overview

It uses the Tape & Reel (TR) package in order to optimize the performance of this voltage regulator. The harley voltage regulator is available as a 8-UFDFN package to save space. The voltage regulator is configured with 1 outputs. As you can see, this DC DC switching regulator generates Adjustable output on its output pins. A Surface Mount mounting is required for this switching regulator. Voltage regulators should be operated at -40°C~85°C TA temperature while operating. Featuring a 1A Switch output current, dc to dc voltage regulator offers maximum design flexibility. There is a voltage regulator maximum input voltage of 5V. At 18V volts, voltage regulator can provide voltage. To operate the voltage regulator 12v, 8 pins are required. Accordingly, dc to dc voltage regulator's maximum output current is 40mA A. By using 18V as the maximum output voltage, adjusting voltage regulator is easy to operate. In order to ensure reliable performance, the dc to dc voltage regulator's minimum supply voltage is 2.9V volts. A switching frequency of 10kHz can improve reliability.
