Manufacturer No:

AS11P2TLRQ

Manufacturer:

ST

Package:

6-UFDFN

Description:

28ns, 21ns SPDT 1.2Ohm Analog Switches AS11P2 20nA 6-UFDFN

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AS11P2TLRQ information

ST AS11P2TLRQ technical specifications, attributes, parameters and parts with similar specifications to ST AS11P2TLRQ.

  • Type
  • Parameter
  • Lifecycle Status
  • NRND (Last Updated: 7 months ago)
  • Contact Plating
  • Gold
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 6-UFDFN
  • Number of Pins
  • 6
  • Weight
  • 21.092045mg
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Cut Tape (CT)
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Resistance
  • 1.2Ohm
  • Max Power Dissipation
  • 1.12W
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • AS11P2
  • Number of Outputs
  • 2
  • Max Supply Voltage
  • 4.5V
  • Min Supply Voltage
  • 1.65V
  • Power Dissipation
  • 1.12W
  • Max Supply Current
  • 1?A
  • Turn On Delay Time
  • 28 ns
  • Number of Inputs
  • 1
  • Supply Type
  • Single
  • -3db Bandwidth
  • 150MHz
  • On-State Resistance (Max)
  • 1.2Ohm
  • Multiplexer/Demultiplexer Circuit
  • 2:1
  • Current - Leakage (IS(off)) (Max)
  • 20nA
  • Channel Capacitance (CS(off), CD(off))
  • 25pF
  • Switch Circuit
  • SPDT
  • Switch Time (Ton, Toff) (Max)
  • 28ns, 21ns
  • Charge Injection
  • 33pC
  • Channel-to-Channel Matching (?Ron)
  • 50m ?
  • Crosstalk
  • -80dB @ 100kHz
  • Voltage - Supply, Single (V+)
  • 1.65V~4.5V
  • Height
  • 500?m
  • Length
  • 1.25mm
  • Width
  • 1.05mm
  • REACH SVHC
  • No SVHC
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for ST AS11P2TLRQ.

Datasheets:

AS11P2TLRQ Overview


Shipping overseas is convenient with the electronic component packed in 6-UFDFN. High reliability is provided by advanced packaging method Cut Tape (CT). In Surface Mount, this analog switch is mounted. Multiplexers and demultiplexers have a ratio of 2:1. Temperatures around -40°C~85°C TA are extended for operation. A SPDT switching circuit is used to build these analog multiplexers. Try searching with AS11P2 if you're looking for variants. There is 1.2Ohm internal resistance in this digital multiplexer. For functions related to 6 pins, please refer to the datasheets. A voltage higher than 4.5V should not normally be supplied to the switches. Analogue multiplexers of the Single supply type that are cost-effective. 1.65V should be the lowest voltage fed to the electronic component. This analog switch requires a voltage of 1.65V~4.5V to drain from a single voltage supply. The analogue multiplexer may be damaged if voltage is greater than 1?A. It is possible to operate 1 inputs. The analogue multiplexer has 2 outputs.

AS11P2TLRQ Features


Switch Circuit: SPDT
-3db Bandwidth: 150MHz


AS11P2TLRQ Applications


There are a lot of STMicroelectronics
AS11P2TLRQ Analog Switches & Multiplexers ICs applications.


  • Transmit
  • Low-Voltage
  • Isolation
  • Medical
  • Imaging
  • Ultrasound
  • Audio and video switching
  • Automatic test equipment
  • Precision data acquisition
  • Battery-powered systems
