BROADCOM ALM-1222-TR1G

Manufacturer No:

ALM-1222-TR1G

Manufacturer:

BROADCOM

Package:

22-SMD Module, No Lead

Description:

29.5dB ~ 32.5dB Cellular, CDMA, W-CDMA, PCS, EGSM NARROW BAND MEDIUM POWER Tape & Reel (TR) 1.8GHz~2.2GHz 1.9V~2.8V P1dB:27.5dBm 0.62dB Surface Mount

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ALM-1222-TR1G information

BROADCOM ALM-1222-TR1G technical specifications, attributes, parameters and parts with similar specifications to BROADCOM ALM-1222-TR1G.

Type
Parameter

Mounting Type
Surface Mount

Package / Case
22-SMD Module, No Lead

Packaging
Tape & Reel (TR)

Published
2009

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
2 (1 Year)

Number of Terminations
22

ECCN Code
EAR99

Additional Feature
LOW NOISE

HTS Code
8542.33.00.01

Subcategory
RF/Microwave Amplifiers

Technology
GAAS

Voltage - Supply
1.9V~2.8V

Number of Functions
1

Construction
COMPONENT

Reach Compliance Code
compliant

Frequency
1.8GHz~2.2GHz

Power Supplies
5V

Test Frequency
2GHz

Current - Supply
280mA

Gain
29.5dB ~ 32.5dB

RF/Microwave Device Type
NARROW BAND MEDIUM POWER

RF Type
Cellular, CDMA, W-CDMA, PCS, EGSM

Input Power-Max (CW)
22dBm

Noise Figure
0.62dB

P1dB
27.5dBm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for BROADCOM ALM-1222-TR1G.

Datasheets:

broadcomlimited-alm1222blkg-datasheets-4886.pdf

ALM-1222-TR1G Overview

The RF amplifier is a cost-effective NARROW BAND MEDIUM POWER RF/Microwave device.The RF amplifier has type Cellular, CDMA, W-CDMA, PCS, EGSM RF.A high level of reliability is provided by using an advanced RF Amp' packaging Tape & Reel (TR).The RF power Amplifier ships overseas conveniently packed in 22-SMD Module, No Lead.In order to mount Amplifiers RF, it is recommended to follow the Surface Mount axis.Amplifiers RFs with 1.9V~2.8V voltage capabilities can be used.Here are the additional features of this RF Amp: LOW NOISEIt has 1 total function(s).For its operation, 280mA is the supply RF Amplifiers' current.A variety of 22 terminations are available.RF Amplifier is a special type of RF/Microwave Amplifiers.

ALM-1222-TR1G Features

NARROW BAND MEDIUM POWER RF/Microwave Amplifier
RF Type Cellular, CDMA, W-CDMA, PCS, EGSM
1.9V~2.8V voltage
280mA current

ALM-1222-TR1G Applications

There are a lot of Broadcom Limited
ALM-1222-TR1G RF Amplifiers applications.

Ultra-Mobile PC
Recreational
Marine Navigation
Avionics
GPS
GLONASS
BeiDou
Galileo
Wireless communications
ISM applications
