ST ALED6001

Manufacturer No:

ALED6001

Manufacturer:

Package:

16-TSSOP (0.173, 4.40mm Width) Exposed Pad

Description:

0.65mm PMIC Automotive, AEC-Q100 Series ALED60 16 Pin 12V 16-TSSOP (0.173, 4.40mm Width) Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ALED6001 information

ST ALED6001 technical specifications, attributes, parameters and parts with similar specifications to ST ALED6001.

Type
Parameter

Lifecycle Status
ACTIVE (Last Updated: 8 months ago)

Factory Lead Time
14 Weeks

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
16-TSSOP (0.173, 4.40mm Width) Exposed Pad

Number of Pins
16

Weight
62.709145mg

Operating Temperature
-40°C~150°C TJ

Packaging
Tube

Series
Automotive, AEC-Q100

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
16

ECCN Code
EAR99

Type
DC DC Controller

Applications
Automotive

Terminal Position
DUAL

Terminal Form
GULL WING

Number of Functions
1

Supply Voltage
12V

Terminal Pitch
0.65mm

Base Part Number
ALED60

Number of Outputs
1

Max Supply Voltage
36V

Max Output Voltage
60V

Topology
SEPIC, Step-Down (Buck), Step-Up (Boost)

Min Input Voltage
5.5V

Max Input Voltage
36V

Internal Switch(s)
No

Dimming
Analog, PWM

Number of Segments
1

Switching Frequency
1MHz

Multiplexed Display Capability
NO

Nominal Input Voltage (DC)
12V

Length
5mm

Width
4.4mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ST ALED6001.

Datasheets:

stmicroelectronics-aled6001tr-datasheets-8206.pdf

ALED6001 Overview

Using its 16-TSSOP (0.173, 4.40mm Width) Exposed Pad package, it is possible to save board space. LED drivers design with 1 outputs.This mounting method is Surface Mount.The system emerges as a DC DC Controller with high efficiency.It is capable of working normally at -40°C~150°C TJ.Automotive has considerable advantages.The operation of this system is supported by 16 terminations.This configuration is built upon 16 pins.1 segments are present.The mount is in the way of Surface Mount.The LED driver is available under the part number ALED60.There is no maximum value acceptable for the supply voltage, so 36V is acceptable.With 5.5V as the minimal input voltage, it operates.The maximum supply current is 36V.It is possible to provide high efficiency when the maximal supply current is less than 7mA.This electronic component can fully perform its functions when the switching frequency is kept at 1MHz.LED drivers belonging to the series Automotive, AEC-Q100 are important components in a wide range of applications.There shouldn't be an increase in output voltage over 60V.

ALED6001 Features

Available in the 16-TSSOP (0.173, 4.40mm Width) Exposed Pad package
Operating temperature of -40°C~150°C TJ
Supply voltage of 12V
Switching frequency of 1MHz

ALED6001 Applications

There are a lot of STMicroelectronics
ALED6001 LED Driver ICs applications.

Gallery lighting
Museum lighting
High-end retail lighting
Medical surgery lighting
Replacement lamps
Panel lighting
Down lights
Linear fluorescent
A- lamps
General LED Lighting: Down-lights, Base-lights, Ceiling Lights, Exterior Lights
