ADI ADSP-TS101SAB1Z000

Manufacturer No:

ADSP-TS101SAB1Z000

Manufacturer:

ADI

Package:

625-BBGA

Description:

1mm Copper, Silver, Tin 6MB CPLD TigerSHARC® Series ADSP-TS101 625 Pin 250MHz 1.25V 625-BBGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADSP-TS101SAB1Z000 information

ADI ADSP-TS101SAB1Z000 technical specifications, attributes, parameters and parts with similar specifications to ADI ADSP-TS101SAB1Z000.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 1 month ago)

Factory Lead Time
8 Weeks

Contact Plating
Copper, Silver, Tin

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
625-BBGA

Number of Pins
625

Operating Temperature
-40°C~85°C TC

Packaging
Tray

Series
TigerSHARC®

JESD-609 Code
e1

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
625

Type
Fixed/Floating Point

Terminal Finish
Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)

Technology
CMOS

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Supply Voltage
1.25V

Terminal Pitch
1mm

Frequency
250MHz

Base Part Number
ADSP-TS101

Pin Count
625

Operating Supply Voltage
1.2V

Interface
Host Interface, Link Port, Multi-Processor

Max Supply Voltage
3.45V

Min Supply Voltage
1.14V

Memory Size
6MB

RAM Size
768kB

Data Bus Width
32b

Number of Timers/Counters
2

Address Bus Width
32

Boundary Scan
YES

Low Power Mode
YES

Voltage - I/O
3.30V

Barrel Shifter
YES

Internal Bus Architecture
SINGLE

Non-Volatile Memory
External

Voltage - Core
1.20V

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for ADI ADSP-TS101SAB1Z000.

Datasheets:

analogdevicesinc-adspts101sab1z000-datasheets-3720.pdf

ConflictMineralStatement:

analogdeviceslineartechnology-lt5400bhms8e8trpbf-conflictmineralstatement-8771.pdf

ADSP-TS101SAB1Z000 Overview

In electronic terms, it is a type of component that comes in the package of type 625-BBGA .Tray is the packaging method provided.Due to its Fixed/Floating Point membership, it is ideal for a wide range of applications.The mounting of the device is done in the direction of Surface Mount.As long as it is operated at the temperature of -40°C~85°C TC, it will operate normally.3.30V refers to the range of analog voltages that can be input or output.The TigerSHARC® series includes this digital signal processor.625 terminations are available for its use.1.25V is the supply voltage.625 component pins are present.Its configuration includes 625 pins.With its base part number of ADSP-TS101, many related parts can be identified.The device is specifically designed to operate at the frequency of 250MHz.As a mounting method, it uses Surface Mount.This device requires a minimum voltage of 1.14V.This device can handle a maximum voltage of 3.45V.This device is powered by 1.2V's supply voltage.6MB data can be stored in the memory of this device.Time and external events are measured and counted with 2 timers/counters.

ADSP-TS101SAB1Z000 Features

Supplied in the 625-BBGA package
Operating supply voltage of 1.2V
2 timers/counters

ADSP-TS101SAB1Z000 Applications

There are a lot of Analog Devices Inc.
ADSP-TS101SAB1Z000 DSP applications.

Speech processing
Radar
Seismology
Audio
Sonar
Voice recognition
Financial signals
Other sensor array processing
Spectral density estimation
Statistical signal processing
