Manufacturer No:

ADRF5045BCCZN

Manufacturer:

ADI

Package:

24-VFLGA Exposed Pad

Description:

General Purpose RF Type SP4T -40°C~85°C TC 9kHz~30GHz Isolation:45dB Insertion Loss:2.4dB Absorptive 50Ohm IIP3:50dBm 3.15V~3.45V

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADRF5045BCCZN information

ADI ADRF5045BCCZN technical specifications, attributes, parameters and parts with similar specifications to ADI ADRF5045BCCZN.

  • Type
  • Parameter
  • Lifecycle Status
  • PRODUCTION (Last Updated: 2 weeks ago)
  • Factory Lead Time
  • 26 Weeks
  • Package / Case
  • 24-VFLGA Exposed Pad
  • Surface Mount
  • YES
  • Number of Pins
  • 24
  • Operating Temperature
  • -40°C~85°C TC
  • Packaging
  • Strip
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 24
  • Voltage - Supply
  • 3.15V~3.45V
  • Terminal Position
  • BOTTOM
  • Terminal Form
  • BUTT
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Number of Functions
  • 1
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.5mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Pin Count
  • 24
  • Circuit
  • SP4T
  • Test Frequency
  • 30GHz
  • Impedance
  • 50Ohm
  • Topology
  • Absorptive
  • Insertion Loss
  • 2.4dB
  • Telecom IC Type
  • TELECOM CIRCUIT
  • Isolation
  • 45dB
  • RF Type
  • General Purpose
  • P1dB
  • 28dBm
  • IIP3
  • 50dBm
  • Neg Supply Voltage-Nom
  • -3.3V
  • Length
  • 4mm
  • Height Seated (Max)
  • 0.96mm
  • Width
  • 4mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ADI ADRF5045BCCZN.

Datasheets:

PCN Design/Specification:

ConflictMineralStatement:

ADRF5045BCCZN Overview


As a result of the use of the Strip package, the performance of this RF Switch is optimized.As you can see, this RF Switch contains 24 terminations.This RF Switch should operate at a temperature of -40°C~85°C TC when operating.In order to operate high power RF switch, there are 24 pins that must be connected.RF Type General Purpose from the RF switch ic.RF Switch is capable of supplying a voltage of 3.15V~3.45V volts.

ADRF5045BCCZN Features


Strip package
24 terminations
24 pins
General Purpose RF Type


ADRF5045BCCZN Applications


There are a lot of Analog Devices Inc.
ADRF5045BCCZN RF Switches applications.


  • Dual-band applications
  • High speed filter selection
  • Digital transceiver front end switch
  • IF switching
  • Tuner modules
  • Antenna diversity switching
  • Cellular/PCS Base Stations
  • ISM
  • Wireless Local Loop
  • Smartphones
