ADI ADRF5027BCCZN-R7

Manufacturer No:

ADRF5027BCCZN-R7

Manufacturer:

ADI

Package:

20-WFLGA Exposed Pad

Description:

VSAT RF Type SPDT -40°C~105°C 9kHz~44GHz Isolation:43dB Insertion Loss:3.8dB Absorptive 50Ohm IIP3:54dBm 3.15V~3.45V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADRF5027BCCZN-R7 information

ADI ADRF5027BCCZN-R7 technical specifications, attributes, parameters and parts with similar specifications to ADI ADRF5027BCCZN-R7.

Type
Parameter

Factory Lead Time
8 Weeks

Package / Case
20-WFLGA Exposed Pad

Surface Mount
YES

Operating Temperature
-40°C~105°C

Packaging
Tape & Reel (TR)

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
20

Voltage - Supply
3.15V~3.45V

Terminal Position
BOTTOM

Terminal Form
NO LEAD

Number of Functions
1

Supply Voltage
3.3V

Terminal Pitch
0.4mm

Reach Compliance Code
compliant

Pin Count
20

JESD-30 Code
S-XBGA-N20

Circuit
SPDT

Supply Voltage-Max (Vsup)
3.45V

Supply Voltage-Min (Vsup)
3.15V

Number of Channels
1

Test Frequency
44GHz

Impedance
50Ohm

Neg Supply Voltage-Nom (Vsup)
-3.3V

Frequency Range
9kHz~44GHz

Insertion Loss
3.8dB

Isolation
43dB

Neg Supply Voltage-Max (Vsup)
-3.45V

RF Type
VSAT

P1dB
26dBm

Neg Supply Voltage-Min (Vsup)
-3.15V

IIP3
54dBm

Length
3mm

Height Seated (Max)
0.776mm

Width
3mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI ADRF5027BCCZN-R7.

Datasheets:

analogdevicesinc-adrf5027evalz-datasheets-3058.pdf

ADRF5027BCCZN-R7 Overview

It is designed to provide optimal performance by utilizing the Tape & Reel (TR) package.There are 20 terminations in this RF Switch.-40°C~105°C should be the operating temperature when RF Switch is operating.The RF switch ic type is VSAT.It is possible for the RF Switch to supply voltages of 3.15V~3.45V.

ADRF5027BCCZN-R7 Features

Tape & Reel (TR) package
20 terminations
VSAT RF Type

ADRF5027BCCZN-R7 Applications

There are a lot of Analog Devices Inc.
ADRF5027BCCZN-R7 RF Switches applications.

Digital transceiver front end switch
IF switching
Tuner modules
Antenna diversity switching
Cellular/PCS Base Stations
ISM
Wireless Local Loop
Smartphones
Tablets
Mobile devices
