ADI ADRF5025BCCZN
ADI ADRF5025BCCZN

ADI ADRF5025BCCZN

Manufacturer No:

ADRF5025BCCZN

Manufacturer:

ADI

Package:

12-VFLGA

Description:

General Purpose RF Type SPDT -40°C~105°C 9kHz~44GHz Isolation:35dB Insertion Loss:1.6dB Reflective 50Ohm IIP3:50dBm 3.15V~3.45V

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADRF5025BCCZN information

ADI ADRF5025BCCZN technical specifications, attributes, parameters and parts with similar specifications to ADI ADRF5025BCCZN.

  • Type
  • Parameter
  • Lifecycle Status
  • PRODUCTION (Last Updated: 3 weeks ago)
  • Factory Lead Time
  • 8 Weeks
  • Package / Case
  • 12-VFLGA
  • Surface Mount
  • YES
  • Mounting Feature
  • SURFACE MOUNT
  • Number of Pins
  • 12
  • Operating Temperature
  • -40°C~105°C
  • Packaging
  • Strip
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 12
  • Technology
  • CMOS
  • Voltage - Supply
  • 3.15V~3.45V
  • Number of Functions
  • 1
  • Construction
  • COMPONENT
  • Pin Count
  • 12
  • Circuit
  • SPDT
  • Power Supplies
  • +-3.3V
  • Test Frequency
  • 44GHz
  • Impedance
  • 50Ohm
  • Topology
  • Reflective
  • Frequency Range
  • 9kHz~44GHz
  • RF/Microwave Device Type
  • DIVERSITY SWITCH
  • Insertion Loss
  • 1.6dB
  • Isolation
  • 35dB
  • Operating Frequency-Min
  • 0.009MHz
  • RF Type
  • General Purpose
  • Input Power-Max (CW)
  • 27.5dBm
  • P1dB
  • 27.5dBm
  • IIP3
  • 50dBm
  • On Time-Nom
  • 1.7 µs
  • 1dB Compression Point
  • 27 dBm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ADI ADRF5025BCCZN.

Datasheets:

ConflictMineralStatement:

ADRF5025BCCZN Overview


This RF Switch utilizes the Strip package for optimized performance.There are 12 terminations in this RF Switch.When operating, RF Switch's operating temperature should be kept at -40°C~105°C.12 pins are used for high power RF switch operation.General Purpose RF Type from the RF switch ic.The RF Switch can supply 3.15V~3.45V voltage.

ADRF5025BCCZN Features


Strip package
12 terminations
12 pins
General Purpose RF Type


ADRF5025BCCZN Applications


There are a lot of Analog Devices Inc.
ADRF5025BCCZN RF Switches applications.


  • Wireless communications
  • General-purpose RF switching
  • Dual-band applications
  • High speed filter selection
  • Digital transceiver front end switch
  • IF switching
  • Tuner modules
  • Antenna diversity switching
  • Cellular/PCS Base Stations
  • ISM

User Guide
