Rochester ADR434BR
Rochester ADR434BR

Rochester ADR434BR

Manufacturer No:

ADR434BR

Manufacturer:

Rochester

Package:

8-SOIC (0.154, 3.90mm Width)

Description:

1.27mm PMIC XFET® Series 7V 8-SOIC (0.154, 3.90mm Width)

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADR434BR information

Rochester ADR434BR technical specifications, attributes, parameters and parts with similar specifications to Rochester ADR434BR.

  • Type
  • Parameter
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 8-SOIC (0.154, 3.90mm Width)
  • Surface Mount
  • YES
  • Packaging
  • Tube
  • Series
  • XFET®
  • JESD-609 Code
  • e0
  • Pbfree Code
  • no
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 8
  • Terminal Finish
  • TIN LEAD
  • Additional Feature
  • OUTPUT VOLTAGE CAN BE ADJUSTED OVER A 0.5 PERCENT RANGE USING TRIM PIN
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 240
  • Number of Functions
  • 1
  • Supply Voltage
  • 7V
  • Terminal Pitch
  • 1.27mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Pin Count
  • 8
  • JESD-30 Code
  • R-PDSO-G8
  • Number of Outputs
  • 1
  • Operating Temperature (Max)
  • 125°C
  • Operating Temperature (Min)
  • -40°C
  • Supply Voltage-Max (Vsup)
  • 18V
  • Temperature Grade
  • AUTOMOTIVE
  • Supply Voltage-Min (Vsup)
  • 6.1V
  • Trim/Adjustable Output
  • YES
  • Analog IC - Other Type
  • THREE TERMINAL VOLTAGE REFERENCE
  • Output Voltage-Max
  • 4.0975V
  • Output Voltage-Min
  • 4.0945V
  • Temp Coef of Voltage-Max
  • 3 ppm/°C
  • Length
  • 4.9mm
  • Height Seated (Max)
  • 1.75mm
  • Width
  • 3.9mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Rochester ADR434BR.

Datasheets:

ADR434BR Overview


The reference voltage makes use of a handy 8-SOIC (0.154, 3.90mm Width) package.The reference voltage is enclosed in the Tube external packaging.8 terminations with various functions.THREE TERMINAL VOLTAGE REFERENCE analog IC is coupled with the reference voltage.It outputs 4.096V voltage according to the test statistics.It is sufficient to generate 1 outputs. The voltage reference ic includes 8 pins.Reflow soldering should be performed at a temperature of 240.Surface Mount is available for demanding PCB design.It requires a 7V supply voltage.A minimum voltage of 6.1V is required to supply it.The greatest voltage output from the voltage reference ic is tested 4.0975V.The voltage reference circuit outputs a voltage 4.0945V less than 4.0945V.It is a gadget from the XFET® series.It has OUTPUT VOLTAGE CAN BE ADJUSTED OVER A 0.5 PERCENT RANGE USING TRIM PIN to better fulfill the purpose.It has a maximum ambient temperature of 125°C.The voltage reference circuit's bottom temperature should be -40°C.

ADR434BR Features


THREE TERMINAL VOLTAGE REFERENCE Analog IC
Peak Reflow Temperature: 240


ADR434BR Applications


There are a lot of Rochester Electronics, LLC
ADR434BR Voltage Reference applications.


  • Portable, battery-powered equipment
  • Cellular phones, notebook computers, PDAs, GPSs, and DMMs
  • Computer workstations
  • Suitable for use with a wide range of video RAMDACs
  • Smart industrial transmitters
  • PCMCIA cards
  • Automotive
  • 3 V/5 V, 8-bit to 12-bit data converters
  • Precision data acquisition systems
  • High resolution converters
