ADI ADP3624ARHZ
Manufacturer No:
ADP3624ARHZ
Manufacturer:
Package:
8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Description:
Surface Mount Tube Active EAR99 Gate Drivers ICs Non-Inverting 2 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad ADP3624 Low-Side
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
ADP3624ARHZ information
ADI ADP3624ARHZ technical specifications, attributes, parameters and parts with similar specifications to ADI ADP3624ARHZ.
- Type
- Parameter
- Lifecycle Status
- PRODUCTION (Last Updated: 1 month ago)
- Factory Lead Time
- 8 Weeks
- Mount
- Surface Mount
- Mounting Type
- Surface Mount
- Package / Case
- 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
- Number of Pins
- 8
- Operating Temperature
- -40°C~150°C TJ
- Packaging
- Tube
- JESD-609 Code
- e3
- Pbfree Code
- no
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Number of Terminations
- 8
- ECCN Code
- EAR99
- Terminal Finish
- Matte Tin (Sn)
- Subcategory
- MOSFET Drivers
- Voltage - Supply
- 4.5V~18V
- Terminal Position
- DUAL
- Terminal Form
- GULL WING
- Peak Reflow Temperature (Cel)
- 260
- Number of Functions
- 2
- Supply Voltage
- 12V
- Terminal Pitch
- 0.65mm
- Time@Peak Reflow Temperature-Max (s)
- 30
- Pin Count
- 8
- Qualification Status
- Not Qualified
- Max Output Current
- 4A
- Operating Supply Current
- 1.2mA
- Nominal Supply Current
- 1.2mA
- Output Current
- 4A
- Max Supply Current
- 3mA
- Propagation Delay
- 35 ns
- Input Type
- Non-Inverting
- Min Input Voltage
- 4.5V
- Max Input Voltage
- 18V
- Rise Time
- 10ns
- Fall Time (Typ)
- 10 ns
- Rise / Fall Time (Typ)
- 10ns 10ns
- Interface IC Type
- BUFFER OR INVERTER BASED MOSFET DRIVER
- Channel Type
- Independent
- Number of Drivers
- 2
- Output Peak Current Limit-Nom
- 4A
- Driven Configuration
- Low-Side
- Gate Type
- N-Channel MOSFET
- Current - Peak Output (Source, Sink)
- 4A 4A
- High Side Driver
- NO
- Logic Voltage - VIL, VIH
- 0.8V 2V
Download datasheets and manufacturer documentation for ADI ADP3624ARHZ.
ConflictMineralStatement:
ADP3624ARHZ Overview
Its 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad package is adopted for higher flexibility.Gate drivers is packaged in the way of Tube.Gate drivers incorporates wGate driversh 2 drivers for Gate driverss configuration.Gate drivers is mounted in the way of Surface Mount.Gate drivers is able to show Gate driverss superiorGate driversy on the basis of a supply voltage of 4.5V~18V.Gate drivers is designed wGate driversh a gate type of N-Channel MOSFET.The allowable temperature range that this device can be operated in is -40°C~150°C TJ.Mosfet driver uses Non-Inverting as Mosfet drivers input type.There are 8 terminations to form the base of its configuration.Under its base part number ADP3624, various related parts can be found.Surface Mount is the way it takes to mount the device.Mosfet driver is configured wMosfet driverh 8 pins when designing.Mosfet driver is specifically designed to opeate wMosfet driverh a supply voltage of 12V.BUFFER OR INVERTER BASED MOSFET DRIVER is employed as its interface IC.The maximum output current can amount to 4A.Its subcategory of MOSFET Drivers contains various useful electronic components.The number of component pins is 8.Mosfet driver supports an output current of 4A.The supply current should be kept at 3mA to ensure higher stability.Mosfet gate drivers operates wMosfet gate driversh the supply voltage of 1.2mA.
