ADI ADP2108ACBZ-1.3-R7
Manufacturer No:
ADP2108ACBZ-1.3-R7
Manufacturer:
Package:
5-WFBGA, WLCSP
Description:
5 Terminals 2.3V 5-Pin ADP2108 DC DC Voltage Regulator SWITCHING REGULATOR 1 Outputs 3MHz Tape & Reel (TR) 5-WFBGA, WLCSP
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
ADP2108ACBZ-1.3-R7 information
ADI ADP2108ACBZ-1.3-R7 technical specifications, attributes, parameters and parts with similar specifications to ADI ADP2108ACBZ-1.3-R7.
- Type
- Parameter
- Contact Plating
- Copper, Silver, Tin
- Mount
- Surface Mount
- Mounting Type
- Surface Mount
- Package / Case
- 5-WFBGA, WLCSP
- Number of Pins
- 5
- Weight
- 42.013993mg
- Operating Temperature
- -40°C~125°C TA
- Packaging
- Tape & Reel (TR)
- JESD-609 Code
- e3
- Pbfree Code
- no
- Part Status
- Obsolete
- Moisture Sensitivity Level (MSL)
- 3 (168 Hours)
- Number of Terminations
- 5
- ECCN Code
- EAR99
- Terminal Finish
- MATTE TIN
- Subcategory
- Switching Regulator or Controllers
- Terminal Position
- BOTTOM
- Terminal Form
- BALL
- Peak Reflow Temperature (Cel)
- 225
- Time@Peak Reflow Temperature-Max (s)
- NOT SPECIFIED
- Base Part Number
- ADP2108
- Function
- Step-Down
- Number of Outputs
- 1
- Qualification Status
- Not Qualified
- Voltage - Input (Max)
- 5.5V
- Output Voltage
- 1.3V
- Output Type
- Fixed
- Max Output Current
- 600mA
- Voltage - Input (Min)
- 2.3V
- Input Voltage-Nom
- 3.6V
- Analog IC - Other Type
- SWITCHING REGULATOR
- Operating Supply Current
- 30?A
- Nominal Supply Current
- 30?A
- Output Configuration
- Positive
- Topology
- Buck
- Control Mode
- CURRENT-MODE
- Frequency - Switching
- 3MHz
- Control Technique
- PULSE WIDTH MODULATION
- Synchronous Rectifier
- Yes
- Min Output Voltage
- 1.3V
- RoHS Status
- RoHS Compliant
- Lead Free
- Contains Lead
