ADI ADL5530ACPZ-WP
Manufacturer No:
ADL5530ACPZ-WP
Manufacturer:
Package:
LFCSP EP
Description:
16.8 dB 1 GHz 3 dB 110 mA
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
ADL5530ACPZ-WP information
ADI ADL5530ACPZ-WP technical specifications, attributes, parameters and parts with similar specifications to ADI ADL5530ACPZ-WP.
- Type
- Parameter
- Lifecycle Status
- Production (Last Updated: 1 month ago)
- Package / Case
- LFCSP EP
- Contact Plating
- Tin
- Mount
- Surface Mount
- Number of Pins
- 8
- Manufacturer Lifecycle Status
- PRODUCTION (Last Updated: 1 month ago)
- Max Operating Temperature
- 85 °C
- Min Operating Temperature
- -40 °C
- Max Power Dissipation
- 550 mW
- Frequency
- 1 GHz
- Operating Supply Voltage
- 5 V
- Number of Channels
- 1
- Max Supply Voltage
- 5.5 V
- Min Supply Voltage
- 3 V
- Operating Supply Current
- 110 mA
- Nominal Supply Current
- 110 mA
- Gain
- 16.8 dB
- -3db Bandwidth
- 1 GHz
- Max Frequency
- 1 GHz
- Noise Figure
- 3 dB
- Length
- 3 mm
- Width
- 2 mm
- Radiation Hardening
- No
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for ADI ADL5530ACPZ-WP.
ADL5530ACPZ-WP Overview
The RF power Amplifier ships overseas conveniently packed in LFCSP EP.This RF Amplifier needs to operate at 110 mA supply current in order to deliver its performance.8 pins are provided on the high power RF Amplifier.Running the RF power Amplifier at 85 °C is ideal.
ADL5530ACPZ-WP Features
8 pins
ADL5530ACPZ-WP Applications
There are a lot of Analog Devices
ADL5530ACPZ-WP RF Amplifiers applications.
- Ultra-Mobile PC
- Recreational
- Marine Navigation
- Avionics
- GPS
- GLONASS
- BeiDou
- Galileo
- Wireless communications
- ISM applications
