Manufacturer No:

ADG798HFRZ

Manufacturer:

ADI

Package:

16-CFlatPack

Description:

30ns, 20ns 10Ohm DUAL Analog Switches ADG798 16 Pins 180nA 16-CFlatPack

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADG798HFRZ information

ADI ADG798HFRZ technical specifications, attributes, parameters and parts with similar specifications to ADI ADG798HFRZ.

  • Type
  • Parameter
  • Lifecycle Status
  • PRODUCTION (Last Updated: 1 week ago)
  • Factory Lead Time
  • 8 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 16-CFlatPack
  • Surface Mount
  • YES
  • Number of Pins
  • 16
  • Operating Temperature
  • -55°C~210°C TA
  • Packaging
  • Tube
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 16
  • Technology
  • CMOS
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • NOT APPLICABLE
  • Number of Functions
  • 1
  • Time@Peak Reflow Temperature-Max (s)
  • NOT APPLICABLE
  • Base Part Number
  • ADG798
  • Pin Count
  • 16
  • Number of Circuits
  • 1
  • Analog IC - Other Type
  • DUAL SWITCHING CONTROLLER
  • Voltage - Supply, Single/Dual (±)
  • 3V~5.5V ±2.5V
  • -3db Bandwidth
  • 55MHz
  • Multiplexer/Demultiplexer Circuit
  • 8:1
  • Current - Leakage (IS(off)) (Max)
  • 180nA
  • Channel Capacitance (CS(off), CD(off))
  • 13pF 85pF
  • Switch Time (Ton, Toff) (Max)
  • 30ns, 20ns
  • Charge Injection
  • 3pC
  • Channel-to-Channel Matching (ΔRon)
  • 1.25 Ω
  • Crosstalk
  • -60dB @ 10MHz
  • Height Seated (Max)
  • 3.02mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Contains Lead

Download datasheets and manufacturer documentation for ADI ADG798HFRZ.

Datasheets:

ConflictMineralStatement:

ADG798HFRZ Overview


Presented in 16-CFlatPack, this electrical component is convenient for overseas shipping. High reliability is ensured by the advanced packaging method Tube. Surface Mount is where this multiplexer is located. Multiplexer and demultiplexer circuits have a number 8:1. Increasing operating temperature to around -55°C~210°C TA. Totally, there are 16 terminations. A total of 16 pins are injected into the electrical part body. The circuits in this analogue multiplexer number 1. Using the ADG798 search parameter, you can discover variants of the switch. For details about the functions of 16 pins, please refer to the datasheets. It is integrated with a DUAL SWITCHING CONTROLLER analog IC.

ADG798HFRZ Features


-3db Bandwidth: 55MHz


ADG798HFRZ Applications


There are a lot of Analog Devices Inc.
ADG798HFRZ Analog Switches & Multiplexers ICs applications.


  • Precision data acquisition
  • Battery-powered systems
  • Sample-and-hold systems
  • Communication systems
  • Data Acquisition Systems
  • Relay Replacement
  • Battery Powered Systems
  • Existing multiplexer applications (both fault-protected and nonfault-protected)
  • New designs requiring multiplexer functions
  • Cellular phones
