ADI ADG3241BKSZ-500RL7
ADI ADG3241BKSZ-500RL7

ADI ADG3241BKSZ-500RL7

Manufacturer No:

ADG3241BKSZ-500RL7

Manufacturer:

ADI

Package:

6-TSSOP, SC-88, SOT-363

Description:

6 Terminations 2.5V 3.3V 6 Pin ADG3241 Signal switch 1 Functions

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ADG3241BKSZ-500RL7 information

ADI ADG3241BKSZ-500RL7 technical specifications, attributes, parameters and parts with similar specifications to ADI ADG3241BKSZ-500RL7.

  • Type
  • Parameter
  • Lifecycle Status
  • PRODUCTION (Last Updated: 1 week ago)
  • Factory Lead Time
  • 8 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 6-TSSOP, SC-88, SOT-363
  • Surface Mount
  • YES
  • Number of Pins
  • 6
  • Weight
  • 28.009329mg
  • Operating Temperature
  • -40°C~85°C
  • Packaging
  • Tape & Reel (TR)
  • JESD-609 Code
  • e4
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 6
  • ECCN Code
  • EAR99
  • Type
  • Bus Switch
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Subcategory
  • Bus Driver/Transceivers
  • Technology
  • CMOS
  • Voltage - Supply
  • 2.5V 3.3V
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Number of Functions
  • 1
  • Time@Peak Reflow Temperature-Max (s)
  • 40
  • Base Part Number
  • ADG3241
  • Pin Count
  • 6
  • Number of Elements
  • 1
  • Circuit
  • 1 x 1:1
  • Power Supplies
  • 2.5/3.3V
  • Supply Voltage-Min (Vsup)
  • 2.3V
  • Operating Supply Current
  • 1?A
  • Number of Ports
  • 2
  • Number of Bits
  • 1
  • Throw Configuration
  • SPST
  • Propagation Delay
  • 225 ps
  • Quiescent Current
  • 200?A
  • Turn On Delay Time
  • 225 ps
  • Logic Function
  • Translator
  • Data Rate
  • 1.5 Gbps
  • Output Characteristics
  • 3-STATE
  • Supply Type
  • Single
  • Bandwidth
  • 770MHz
  • Output Polarity
  • TRUE
  • -3db Bandwidth
  • 770MHz
  • High Level Output Current
  • -25mA
  • Low Level Output Current
  • 25mA

Download datasheets and manufacturer documentation for ADI ADG3241BKSZ-500RL7.

Datasheets:

ConflictMineralStatement:

ADG3241BKSZ-500RL7 Overview
