ADI AD9977BBCZ

Manufacturer No:

AD9977BBCZ

Manufacturer:

ADI

Package:

84-LFBGA, CSPBGA

Description:

84-LFBGA, CSPBGA Tray Active Sensor & Detector Interface ICs CCD Signal Processor, 14-Bit Surface Mount 3 (168 Hours) ROHS3 Compliant

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AD9977BBCZ information

ADI AD9977BBCZ technical specifications, attributes, parameters and parts with similar specifications to ADI AD9977BBCZ.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 5 days ago)

Contact Plating
Copper, Silver, Tin

Mount
Surface Mount

Mounting Type
Surface Mount

Package / Case
84-LFBGA, CSPBGA

Number of Pins
84

Operating Temperature
-25°C~85°C

Packaging
Tray

JESD-609 Code
e1

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
84

Type
CCD Signal Processor, 14-Bit

Terminal Finish
Tin/Silver/Copper (Sn/Ag/Cu)

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Time@Peak Reflow Temperature-Max (s)
30

Base Part Number
AD9977

Pin Count
84

Output Type
LVDS

Number of Channels
2

Max Supply Voltage
2V

Min Supply Voltage
1.6V

Power Dissipation
340mW

Input Type
Serial

Resolution
1.75 B

Sampling Rate
65 Msps

Max Frequency
65MHz

Conversion Rate
65 Msps

Height
1.11mm

Length
6.1mm

Width
6.1mm

REACH SVHC
No SVHC

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for ADI AD9977BBCZ.

ConflictMineralStatement:

analogdeviceslineartechnology-lt5400bhms8e8trpbf-conflictmineralstatement-8771.pdf

AD9977BBCZ Overview

The product is packaged with the materials of Tray.In order to save space, 84-LFBGA, CSPBGA packages are used.This type of CCD Signal Processor, 14-Bit provides superior performance.Sensor and detector interface is mounted using the Surface Mount technique.To avoid unnecessary cooling processes, it is recommended that the operating temperature be kept at -25°C~85°C.The input type is Serial.In order to prevent signals from reflecting off the end of the transmission line, 84 terminations are used.Electronic parts related to this part can be found by using its base part number AD9977.A number of 1 functions have been configured.Electronic devices with 84-pins are used in this device.Pins on 84 components are designed to perform the specified functions.There is a mounting in the way of Surface Mount.As an output type, it uses LVDS.A failure will occur if the supply voltage exceeds 2V.If the supply voltage is below 1.6V, failures will occur.Data transmission is carried out via 2 channels.
