ADI AD9164BBCZ

Manufacturer No:

AD9164BBCZ

Manufacturer:

ADI

Package:

165-VFBGA, CSPBGA

Description:

DAC Current - Unbuffered Surface Mount Quad-Switch R 8mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AD9164BBCZ information

ADI AD9164BBCZ technical specifications, attributes, parameters and parts with similar specifications to ADI AD9164BBCZ.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 1 month ago)

Factory Lead Time
8 Weeks

Mounting Type
Surface Mount

Package / Case
165-VFBGA, CSPBGA

Surface Mount
YES

Number of Pins
165

Operating Temperature
-40°C~85°C

Packaging
Tray

JESD-609 Code
e1

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
165

Terminal Finish
Tin/Silver/Copper (Sn/Ag/Cu)

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
1.2V

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
30

Base Part Number
AD9164

Pin Count
165

Output Type
Current - Unbuffered

Architecture
Quad-Switch

Converter Type
D/A CONVERTER

Reference Type
External, Internal

Data Interface
JESD204B

Differential Output
No

Voltage - Supply, Analog
1.14V~1.326V 2.375V~2.625V

Voltage - Supply, Digital
1.14V~1.326V

Input Bit Code
2'S COMPLEMENT

INL/DNL (LSB)
±2.7, ±1.7

Negative Supply Voltage-Nom
-1.2V

Input Format
SERIAL

Number of D/A Converters
1

Length
8mm

Height Seated (Max)
0.86mm

Width
8mm

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for ADI AD9164BBCZ.

Datasheets:

analogdevicesinc-ad9164bbca-datasheets-7552.pdf

ConflictMineralStatement:

analogdeviceslineartechnology-lt5400bhms8e8trpbf-conflictmineralstatement-8771.pdf

AD9164BBCZ Overview

As part of the 165-VFBGA, CSPBGA package, it is included. It is powered from a supply voltage of 1.2V. With a Surface Mount connector, this FPGA module can be attached to the development board. It is important to maintain the operating temperature within the range of -40°C~85°C when operating the machine. In order to save space, this FPGA model has been contained in Tray. There are a total of 165 terminations. Its base part number AD9164 can be used to find parts that are related to it. There are 165 pins on this device. There are a total of 165 pins on this device.
