ADI AD7284WBSWZ

Manufacturer No:

AD7284WBSWZ

Manufacturer:

ADI

Package:

64-LQFP Exposed Pad

Description:

-40°C~150°C TJ 8 Channel QUAD Battery Management ICs AD7284 64 Pins 8 Cell Lithium-Ion 64-LQFP Exposed Pad

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AD7284WBSWZ information

ADI AD7284WBSWZ technical specifications, attributes, parameters and parts with similar specifications to ADI AD7284WBSWZ.

Type
Parameter

Lifecycle Status
PRODUCTION (Last Updated: 3 weeks ago)

Factory Lead Time
14 Weeks

Mounting Type
Surface Mount

Package / Case
64-LQFP Exposed Pad

Surface Mount
YES

Number of Pins
64

Operating Temperature
-40°C~150°C TJ

Packaging
Tray

Pbfree Code
no

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
64

Terminal Position
QUAD

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Terminal Pitch
0.5mm

Time@Peak Reflow Temperature-Max (s)
30

Base Part Number
AD7284

Function
Battery Monitor

Supply Voltage-Max (Vsup)
40V

Supply Voltage-Min (Vsup)
10V

Number of Channels
8

Interface
SPI

Analog IC - Other Type
POWER SUPPLY MANAGEMENT CIRCUIT

Fault Protection
Over/Under Voltage

Battery Chemistry
Lithium-Ion

Number of Cells
8

Length
10mm

Height Seated (Max)
1.6mm

Width
10mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI AD7284WBSWZ.

Datasheets:

analogdevicesinc-ad7284wbswz-datasheets-9421.pdf

ConflictMineralStatement:

analogdeviceslineartechnology-lt5400bhms8e8trpbf-conflictmineralstatement-8771.pdf

AD7284WBSWZ Overview

The package 64-LQFP Exposed Pad is appropriate for battery instrument. This power management IC utilizes an analog IC POWER SUPPLY MANAGEMENT CIRCUIT. A total of 8 channels are available. 64 pins are on it. The package contains a Tray case. Surface Mount is in the way of this electronic component. The Battery Monitor functions are available. For the electric part to perform effectively, it should operate at a temperature around -40°C~150°C TJ. This electronic part has a chemistry of Lithium-Ion. A AD7284 family is used in it. There is a maximum supply voltage (Vsup) of 40V. A voltage greater than 10V must be present in Vsup (supply voltage).

AD7284WBSWZ Features

Available in 64-LQFP Exposed Pad Package
with 64 Pins
Mounting Type: Surface Mount
Battery Chemistry : Lithium-Ion
Supply Voltage-Max (Vsup) : 40V

AD7284WBSWZ Applications

There are a lot of Analog Devices Inc.
AD7284WBSWZ Battery Management ICs applications.

Golf carts
Electric-powered machinery
Fork lifts
Grid power infrastructure
Cell phone towers
A/C power substations
Internet infrastructure equipment
Aviation ground support systems
Tower communications
Weather stations
