ADI AD5758BCPZ-RL7
ADI AD5758BCPZ-RL7

ADI AD5758BCPZ-RL7

Manufacturer No:

AD5758BCPZ-RL7

Manufacturer:

ADI

Package:

32-VFQFN Exposed Pad, CSP

Description:

Tape & Reel (TR) Active 16 b b Special Purpose ADCs/DACs Serial, SPI ±33V V 32-VFQFN Exposed Pad, CSP Surface Mount

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AD5758BCPZ-RL7 information

ADI AD5758BCPZ-RL7 technical specifications, attributes, parameters and parts with similar specifications to ADI AD5758BCPZ-RL7.

  • Type
  • Parameter
  • Factory Lead Time
  • 10 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 32-VFQFN Exposed Pad, CSP
  • Surface Mount
  • YES
  • Operating Temperature
  • -40°C~115°C
  • Packaging
  • Tape & Reel (TR)
  • Pbfree Code
  • no
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 32
  • Type
  • DAC
  • Voltage - Supply
  • ±33V
  • Terminal Position
  • QUAD
  • Terminal Form
  • NO LEAD
  • Number of Functions
  • 1
  • Supply Voltage
  • 15V
  • Terminal Pitch
  • 0.5mm
  • Pin Count
  • 32
  • JESD-30 Code
  • S-XQCC-N32
  • Number of Channels
  • 1
  • Number of Bits
  • 16
  • Data Interface
  • Serial, SPI
  • Input Bit Code
  • BINARY
  • Voltage Supply Source
  • Dual ±
  • Resolution (Bits)
  • 16 b
  • Length
  • 5mm
  • Width
  • 5mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ADI AD5758BCPZ-RL7.

Datasheets:

AD5758BCPZ-RL7 Description


The AD5758BCPZ-RL7 is a single-channel, voltage and current output digital-to-analogue converter (DAC) that operates with a power supply range from ?33 v (minimum) on avss to +33 v (maximum) on avdd1 with a maximum opera/Ang voltage between the two rails of 60 v.



AD5758BCPZ-RL7 Features


  • 16-bit resolution and monotonicity

  • DPC for thermal management

  • Current/voltage output available on a single terminal

  • Current output ranges: 0 mA to 20 mA, 4 mA to 20 mA,

  • 0 mA to 24 mA, ±20 mA, ±24 mA, ?1 mA to +22 mA

  • Voltage output ranges (with 20% over range): 0 V to 5 V,

  • 0 V to 10 V, ±5 V, and ±10 V

  • User-programmable offset and gain

  • Advanced on-chip diagnostics, including a 12-bit ADC

  • On-chip reference

  • Robust architecture, including output fault protection



AD5758BCPZ-RL7 Applications


  • Process control

  • Actuator control

  • Channel-isolated analogue outputs

  • Programmable logic controller (PLC) and distributed control systems (DCS) applications

  • HART network connectivity
