ADI AD5674RBCPZ-1-RL7

Manufacturer No:

AD5674RBCPZ-1-RL7

Manufacturer:

ADI

Package:

28-VFQFN Exposed Pad, CSP

Description:

DAC Voltage - Buffered Surface Mount String DAC R 4mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AD5674RBCPZ-1-RL7 information

ADI AD5674RBCPZ-1-RL7 technical specifications, attributes, parameters and parts with similar specifications to ADI AD5674RBCPZ-1-RL7.

Type
Parameter

Factory Lead Time
2 Weeks

Mounting Type
Surface Mount

Package / Case
28-VFQFN Exposed Pad, CSP

Surface Mount
YES

Operating Temperature
-40°C~125°C

Series
nanoDAC+®

Pbfree Code
no

Part Status
Active

Number of Terminations
28

Terminal Position
QUAD

Number of Functions
1

Supply Voltage
3V

Terminal Pitch
0.4mm

Reach Compliance Code
compliant

Pin Count
28

JESD-30 Code
S-XQCC-N28

Output Type
Voltage - Buffered

Number of Bits
12

Supply Current-Max
4.2mA

Architecture
String DAC

Converter Type
D/A CONVERTER

Reference Type
Internal

Data Interface
DSP, SPI

Differential Output
No

Voltage - Supply, Digital
1.62V~5.5V

Settling Time
8?s

Linearity Error-Max (EL)
0.0244%

Input Bit Code
BINARY

INL/DNL (LSB)
±0.12LSB, ±0.05LSB

Input Format
SERIAL

Number of D/A Converters
16

Analog Output Voltage-Max
5V

Length
4mm

Height Seated (Max)
1mm

Width
4mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for ADI AD5674RBCPZ-1-RL7.

Datasheets:

analogdevicesinc-ad5679bcpz1-datasheets-3122.pdf

AD5674RBCPZ-1-RL7 Overview

This package is included in the 28-VFQFN Exposed Pad, CSP package and is available for purchase. 3V volts power it. Using a Surface Mount connector, you can mount this FPGA module on the development board. An FPGA belonging to the nanoDAC+® series is referred to as an FPGA. In order to ensure a safe and efficient operation, it is important to maintain a temperature within -40°C~125°C at all times. The total number of terminations is 28. The device has a total of 28 pins on it.
