ADI AD208AY

Manufacturer No:

AD208AY

Manufacturer:

ADI

Package:

38-SIP, 10 Leads, Offset Leads

Description:

1 Channels 2mA per Channel 10nA 100 dB Instrumentational OP Amps 15V 14.25V~15.75V AD208 10 Pins 38-SIP, 10 Leads, Offset Leads

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

AD208AY information

ADI AD208AY technical specifications, attributes, parameters and parts with similar specifications to ADI AD208AY.

Type
Parameter

Lifecycle Status
OBSOLETE (Last Updated: 5 days ago)

Contact Plating
Lead, Tin

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
38-SIP, 10 Leads, Offset Leads

Number of Pins
10

Operating Temperature
-40°C~85°C

Packaging
Tube

Pbfree Code
no

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
11

ECCN Code
EAR99

Technology
HYBRID

Terminal Position
DUAL

Number of Functions
1

Supply Voltage
15V

Terminal Pitch
2.54mm

Base Part Number
AD208

Pin Count
10

Operating Supply Voltage
15V

Number of Channels
1

Operating Supply Current
5mA

Slew Rate
0.1V/?s

Common Mode Rejection Ratio
100 dB

Current - Input Bias
10nA

Voltage - Supply, Single/Dual (±)
14.25V~15.75V

Output Current per Channel
2mA

Input Offset Voltage (Vos)
270?V

Bandwidth
4 kHz

Voltage - Input Offset
250?V

-3db Bandwidth
0.4MHz

Isolation Voltage
1.5kV

Voltage Gain-Min
1

Common Mode Voltage-Max
750V

Height
15.9mm

Length
52.8mm

Width
6.6mm

REACH SVHC
Unknown

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Contains Lead

Download datasheets and manufacturer documentation for ADI AD208AY.

AD208AY Overview

The linear amplifier is packaged in a 38-SIP, 10 Leads, Offset Leads case which makes it easy for the consumer to handle. Op amps are Isolation types of amplifier on the chip. It comes in a Tube case, which protects instrumentation amplifier from damage during delivery. There have been a total of 11 terminations over the past year. In this case, there are 10 pins on the board. Please take in mind that op amp should be run at 15V. 10 pins are available on the instrumentation amplifier. With regard to input offset voltage, instrumentation amplifier is rated at 270?V. This electronic part is best mounted with type Through Hole. Regarding the operating temperature of this device, instrumentation amplifier performs well at a temperature of -40°C~85°C . You can run this op amp ic on 5mA . Instrumentation amplifier has 1 channels on it. The operating supply voltage of instrumentation amplifier is rated 15V voltage. A voltage gain of 1 is the minimum this op amp can achieve.

AD208AY Features

10 Pins
supply voltage of 15V

AD208AY Applications

There are a lot of Analog Devices Inc.
AD208AY Instrumentational OP Amps applications.

Proportional operation circuits
Inverse/same-phase proportional circuit
Addition operation circuits
Subtraction operation circuits
single/dual op amp sum and difference circuits
Integrator circuits
Differentiator circuits
Logarithmic operation circuits
Exponential operation circuits
Multiplication circuits
