BROADCOM ACHS-7122-000E

Manufacturer No:

ACHS-7122-000E

Manufacturer:

BROADCOM

Package:

8-SOIC (0.154, 3.90mm Width)

Description:

Analog Circuit,

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ACHS-7122-000E information

BROADCOM ACHS-7122-000E technical specifications, attributes, parameters and parts with similar specifications to BROADCOM ACHS-7122-000E.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
BROADCOM INC

Reach Compliance Code
compliant

HTS Code
8542.39.00.01

Factory Lead Time
14 Weeks

Samacsys Manufacturer
Avago Technologies

Body Breadth
3.937 mm

Body Height
1.908 mm

Body Length or Diameter
5.08 mm

Mounting Feature
SURFACE MOUNT

Number of Terminals
8

Operating Temperature-Max
110 °C

Operating Temperature-Min
-40 °C

Output Type
VOLTAGE OUTPUT

Package Body Material
PLASTIC/EPOXY

Package Equivalence Code
SOP8,.25

Package Shape/Style
RECTANGULAR

Sensors/Transducers Type
CURRENT SENSOR

Supply Voltage-Max
5.5 V

Supply Voltage-Min
4.5 V

Surface Mount
YES

Terminal Finish
TIN

Download datasheets and manufacturer documentation for BROADCOM ACHS-7122-000E.

Datasheets:

AVGO-S-A0012934361-1.pdf

ACHS-7122-000E Overview

Current sensors are housed in 8-SOIC (0.154, 3.90mm Width) packages to ensure their safety. It is designed to protect the current sensors from damage by packaging them in the Tube. In general, current sensors should provide no more than 15mA amps of current.

ACHS-7122-000E Features

Moisture Sensitivity Level: 1 (Unlimited)
Operating Temperature: -40°C~110°C
Mounting Type: Surface Mount
Sensor Type: Hall Effect
Supply Voltage: 4.5V~5.5V
Frequency: 80kHz
Sensing Current: 20A
8-SOIC (0.154, 3.90mm Width) Package

ACHS-7122-000E Applications

There are a lot of Broadcom Limited
ACHS-7122-000E Current Sensors applications.

Leakage Current Sensors
Industrial Monitoring and Control Systems
Overcurrent Detection
Frequency, Voltage, and Solar Inverters
Electrical drives
General purpose inverters
AC variable speed drives
Static converters for DC motor drives
Battery supplied applications
Uninterruptible Power Supplies(UPS)
