Sullins Connector Solutions ABB10DYHR
Sullins Connector Solutions ABB10DYHR

Sullins Connector Solutions ABB10DYHR

Manufacturer No:

ABB10DYHR

Manufacturer:

Sullins Connector Solutions

Package:

Description:

Female Black 0.050 1.27mm Beryllium Copper 2 Rows Tube Solder, Staggered Gold 20 Positions Polyphenylene Sulfide (PPS)

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ABB10DYHR information

Sullins Connector Solutions ABB10DYHR technical specifications, attributes, parameters and parts with similar specifications to Sullins Connector Solutions ABB10DYHR.

  • Type
  • Parameter
  • Factory Lead Time
  • 3 Weeks
  • Contact Material
  • Beryllium Copper
  • Mounting Type
  • Through Hole
  • Material - Insulation
  • Polyphenylene Sulfide (PPS)
  • Mounting Option 1
  • LOCKING
  • Operating Temperature
  • -65°C~150°C
  • Packaging
  • Tube
  • Published
  • 2016
  • JESD-609 Code
  • e3
  • Feature
  • Board Lock
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder, Staggered
  • Connector Type
  • CARD EDGE CONNECTOR
  • Number of Positions
  • 20
  • Color
  • Black
  • Number of Rows
  • 2
  • Gender
  • Female
  • Subcategory
  • Headers and Edge Type Connectors
  • Contact Type
  • Cantilever
  • Pitch
  • 0.050 1.27mm
  • Total Number of Contacts
  • 20
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL
  • Reliability
  • COMMERCIAL
  • Body Length or Diameter
  • 1.34 inch
  • Number Of PCB Rows
  • 4
  • Body Breadth
  • 0.37 inch
  • Body Depth
  • 0.61 inch
  • Rated Current (Signal)
  • 1A
  • Contact Resistance
  • 30mOhm
  • Card Type
  • Non Specified - Dual Edge
  • Read Out
  • Dual
  • Insulation Resistance
  • 5000000000Ohm
  • Number of Positions/Bay/Row
  • 10
  • Durability
  • 500 Cycles
  • Insertion Force-Max
  • 1.668 N
  • Withdrawl Force-Min
  • .139 N
  • Contact Finish Thickness
  • 10.0μin 0.25μm
  • Card Thickness
  • 0.062 1.57mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Sullins Connector Solutions ABB10DYHR.

Datasheets:

Environmental Information:

ABB10DYHR Overview


A package was prepared according to Tube's specifications.It is recommended to mount the device using type Through Hole.The device is connected using the connector socket CARD EDGE CONNECTOR.Board Lock features are present on the device.
