Manufacturer No:

ABB09DYHN

Manufacturer:

Sullins Connector Solutions

Package:

Description:

Female Black 0.050 1.27mm Beryllium Copper 2 Rows Tube Solder, Staggered Gold 18 Positions Polyphenylene Sulfide (PPS)

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

ABB09DYHN information

Sullins Connector Solutions ABB09DYHN technical specifications, attributes, parameters and parts with similar specifications to Sullins Connector Solutions ABB09DYHN.

  • Type
  • Parameter
  • Factory Lead Time
  • 3 Weeks
  • Contact Material
  • Beryllium Copper
  • Mounting Type
  • Through Hole
  • Material - Insulation
  • Polyphenylene Sulfide (PPS)
  • Mounting Option 1
  • LOCKING
  • Operating Temperature
  • -65°C~150°C
  • Packaging
  • Tube
  • Published
  • 2016
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder, Staggered
  • Connector Type
  • CARD EDGE CONNECTOR
  • Number of Positions
  • 18
  • Color
  • Black
  • Number of Rows
  • 2
  • Gender
  • Female
  • Subcategory
  • Headers and Edge Type Connectors
  • Contact Type
  • Cantilever
  • Pitch
  • 0.050 1.27mm
  • Total Number of Contacts
  • 18
  • Number of Conductors
  • ONE
  • Reference Standard
  • UL
  • Contact Finish
  • Gold
  • Number Of PCB Rows
  • 4
  • Body Breadth
  • 0.37 inch
  • Body Depth
  • 0.61 inch
  • Rated Current (Signal)
  • 1A
  • Contact Resistance
  • 30mOhm
  • Card Type
  • Non Specified - Dual Edge
  • Read Out
  • Dual
  • Insulation Resistance
  • 5000000000Ohm
  • Number of Positions/Bay/Row
  • 9
  • Durability
  • 500 Cycles
  • Insertion Force-Max
  • 1.668 N
  • Contact Finish Thickness
  • 10.0μin 0.25μm
  • Plating Thickness
  • 10μin
  • Card Thickness
  • 0.062 1.57mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Sullins Connector Solutions ABB09DYHN.

Datasheets:

Environmental Information:

ABB09DYHN Overview


The material was packaged in accordance with Tube's specifications.We recommend mounting type Through Hole.Using the connector socket CARD EDGE CONNECTOR is how the device is connected.

ABB09DYHN Features




ABB09DYHN Applications


There are a lot of Sullins Connector Solutions
ABB09DYHN Edgeboard Connectors applications.


  • Digital Multimeters, PLC's (Programming Logic Controllers)
  • RADAR processing, digital oscilloscopes
  • CMOS Image sensors for mobile applications
  • Medical Instrumentation and medical imaging
  • Music recording
  • Digital signal processing
  • Scientific instruments
  • Rotary encoder
  • Displaying
  • Transducer

User Guide
