TT Electronics A2500R24A-EZ4A
Manufacturer No:
A2500R24A-EZ4A
Manufacturer:
Package:
Module
Description:
AIR Series Transceiver, ISM Board(s) 2.4GHz 3.6V 24 Pins Module SPI
Quantity:
Delivery:
Payment:
In Stock :Available
Price not displayed? Please send an RFQ, and we will respond immediately.
A2500R24A-EZ4A information
TT Electronics A2500R24A-EZ4A technical specifications, attributes, parameters and parts with similar specifications to TT Electronics A2500R24A-EZ4A.
- Type
- Parameter
- Factory Lead Time
- 8 Weeks
- Package / Case
- Module
- Number of Pins
- 24
- Series
- AIR
- Published
- 2007
- Part Status
- Active
- Moisture Sensitivity Level (MSL)
- 1 (Unlimited)
- Type
- Transceiver, ISM
- Max Operating Temperature
- 85°C
- Min Operating Temperature
- -40°C
- Frequency
- 2.4GHz
- Operating Supply Voltage
- 3.6V
- Interface
- SPI
- Supplied Contents
- Board(s)
- Evaluation Kit
- Yes
- Height
- 3.2mm
- Length
- 34.5mm
- Width
- 19.7mm
- REACH SVHC
- No SVHC
- RoHS Status
- RoHS Compliant
Download datasheets and manufacturer documentation for TT Electronics A2500R24A-EZ4A.
A2500R24A-EZ4A Overview
The RF Board is conveniently packaged in Module, making it easy to ship internationally.There are 24 pins on the high power RF circuit board.The temperature should not exceed 85°C degrees Celsius.Transceiver, ISM RF Type from the Evaluation board.The RF Board is a kind of the well-known AIR series of products.
A2500R24A-EZ4A Features
Packed in Module
24 pins
85°C degrees Celsius
Transceiver, ISM Type
A2500R24A-EZ4A Applications
There are a lot of Anaren
A2500R24A-EZ4A RF Boards applications.
- Radio Transceiver
- Embedded Processor
- Networking Software
- Forming a Self-Healing
- Mesh Network
- MCU
- Transceiver
- Modem
- MAC
- PA
