Manufacturer No:

A1174EEWLT-P

Manufacturer:

ALLEGRO

Package:

6-XFDFN Exposed Pad

Description:

Push-Pull 1.65V~3.5V -40°C~85°C TA Latch South Pole 5.5mT Trip, -5.5mT Release 2mA-Supply (Max) Nickel/Palladium/Gold (Ni/Pd/Au) 6-XFDFN Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

A1174EEWLT-P information

ALLEGRO A1174EEWLT-P technical specifications, attributes, parameters and parts with similar specifications to ALLEGRO A1174EEWLT-P.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 6-XFDFN Exposed Pad
  • Number of Pins
  • 6
  • Operating Temperature
  • -40°C~85°C TA
  • Packaging
  • Tape & Reel (TR)
  • Published
  • 1996
  • JESD-609 Code
  • e4
  • Pbfree Code
  • yes
  • Part Status
  • Obsolete
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 6
  • Terminal Finish
  • Nickel/Palladium/Gold (Ni/Pd/Au)
  • Subcategory
  • Other Sensors/Transducers
  • Technology
  • Hall Effect
  • Voltage - Supply
  • 1.65V~3.5V
  • Function
  • Latch
  • Current - Supply (Max)
  • 2mA
  • Body Length or Diameter
  • 2mm
  • Body Breadth
  • 1.5 mm
  • Output Type
  • Push-Pull
  • Max Output Current
  • 1mA
  • Power Supplies
  • 1.8/3.3V
  • Termination Type
  • SOLDER
  • Polarization
  • South Pole
  • Test Condition
  • -40°C ~ 85°C
  • Sensing Range
  • 5.5mT Trip, -5.5mT Release
  • Hysteresis
  • 7.2 mT
  • Output Range
  • 300mV
  • Magnetic Field Range-Min
  • -5.5 mT
  • Magnetic Field Range-Max
  • 5.5 mT
  • Body Height
  • 0.38mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for ALLEGRO A1174EEWLT-P.

Datasheets:

A1174EEWLT-P Overview


Designed to protect magnetic switches from damage, the Tape & Reel (TR) package contains the switches. In order to ensure safety, magnetic switches are packaged in 6-XFDFN Exposed Pad packages. In order to function well, magnetic switches should be able to supply a maximum current of 2mA. The maximum current these switches can supply when they work is 1mA. Switches have 6 pins for operation. This termination has 6 terminations.
