Manufacturer No:

8N3Q001LG-0117CDI

Manufacturer:

Renesas

Package:

CLCC

Description:

2.5V LVPECL Programmable Timers 312.5MHz 2.5V CLCC

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

8N3Q001LG-0117CDI information

Renesas 8N3Q001LG-0117CDI technical specifications, attributes, parameters and parts with similar specifications to Renesas 8N3Q001LG-0117CDI.

  • Type
  • Parameter
  • Mount
  • Surface Mount
  • Package / Case
  • CLCC
  • Number of Pins
  • 10
  • Packaging
  • Bulk
  • Published
  • 2007
  • ECCN Code
  • EAR99
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Additional Feature
  • ENABLE/DISABLE FUNCTION; DIFFERENTIAL OUTPUT; SELECTABLE O/P FREQUENCIES; TRAY
  • HTS Code
  • 8542.39.00.01
  • Supply Voltage
  • 2.5V
  • Depth
  • 5mm
  • Frequency
  • 312.5MHz
  • Frequency Stability
  • 20 ppm
  • Physical Dimension
  • 7.0mm x 5.0mm x 1.55mm
  • Operating Frequency
  • 156.25MHz
  • Operating Supply Voltage
  • 2.5V
  • Rise Time-Max
  • 0.425ns
  • Fall Time-Max
  • 0.425ns
  • Symmetry-Max
  • 55/45%
  • Supply Voltage-Max (Vsup)
  • 2.625V
  • Operating Supply Current
  • 136mA
  • Oscillator Type
  • LVPECL
  • Output Load
  • 50 OHM
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas 8N3Q001LG-0117CDI.

Datasheets:

8N3Q001LG-0117CDI Overview


In the packaging with the CLCC, there is a programmable timer enclosed in the package. A frequency of 312.5MHz is set for the programmable timer.It is used to pack in Bulk case. To mount this digital timer with Surface Mount. The operating supply voltage is rated at 136mA voltage. The minimum operating temperature of the chip must not be lower than -40°C. It's best to use the timer clock when the temperature is below 85°C. The types of oscillator includes LVPECL. The timer clock contains 10 pins. The digital timer's operating supply voltage is rated 2.5V voltage. The supply voltage of the programmable timer can rate 2.5V. You can read the timer clock's additional feature in the follwing: ENABLE/DISABLE FUNCTION; DIFFERENTIAL OUTPUT; SELECTABLE O/P FREQUENCIES; TRAY. On operating frequency, it's available in the range of 156.25MHz.
