Preci-Dip 892-70-028-10-002101

Manufacturer No:

892-70-028-10-002101

Manufacturer:

Package:

Description:

892 Series 2-Row Header Solder Brass Bulk Through Hole Gold Polyamide (PA), Nylon, Glass Filled 28-Position Board to Board 0.100 2.54mm Height

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

892-70-028-10-002101 information

Preci-Dip 892-70-028-10-002101 technical specifications, attributes, parameters and parts with similar specifications to Preci-Dip 892-70-028-10-002101.

Type
Parameter

Factory Lead Time
10 Weeks

Contact Material
Brass

Mount
Through Hole

Mounting Type
Through Hole

Contact Shape
Square

Insulation Material
Polyamide (PA), Nylon, Glass Filled

Operating Temperature
-55°C~125°C

Packaging
Bulk

Series
892

Published
2012

JESD-609 Code
e4

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
Solder

Connector Type
Header

Number of Positions
28

Number of Rows
2

Voltage - Rated
150VDC

Fastening Type
Push-Pull

Contact Finish - Mating
Gold

MIL Conformance
NO

DIN Conformance
NO

IEC Conformance
NO

Contact Type
Male Pin

Mixed Contacts
NO

Option
GENERAL PURPOSE

Current Rating (Amps)
3A

Insulation Height
0.100 2.54mm

Style
Board to Board

Number of Positions Loaded
All

Pitch - Mating
0.100 2.54mm

Insulation Color
Black

Number of Conductors
ONE

Reference Standard
UL

Reliability
COMMERCIAL

Body Length or Diameter
1.4 inch

Row Spacing - Mating
0.100 (2.54mm)

Contact Length - Post
0.118 3.00mm

Shrouding
Unshrouded

Contact Length - Mating
0.276 7.00mm

UL Flammability Code
94V-0

Body Depth
0.1 inch

Overall Contact Length
0.494 12.54mm

Insulation Resistance
10000000000Ohm

Mating Contact Pitch
0.1 inch

Dielectric Withstanding Voltage
1400VAC V

Download datasheets and manufacturer documentation for Preci-Dip 892-70-028-10-002101.

Datasheets:

precidip-8921800410001101-datasheets-8648.pdf

Environmental Information:

precidip-9991921006-environmentalinformation-0838.pdf

892-70-028-10-002101 Overview

It comes in Header packaging.The device's mounting type is Through Hole.In order to package the product, a Bulk case is used.It belongs to the 892 Series of products.The part is mounted by Through Hole.The device runs in -55°C~125°C Operating Temperature.

892-70-028-10-002101 Features

892 series

892-70-028-10-002101 Applications

There are a lot of Preci-Dip
892-70-028-10-002101 Rectangular Connectors applications.

Industrial Automation
Transportation
Embedded systems
Datacom
Communication
Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
