Weidmüller 8768650000

Manufacturer No:

8768650000

Manufacturer:

Weidmüller

Package:

Module

Description:

Silicon Carbide Schottky Rectifier Diode 1 Pair Common Cathode -10°C~55°C 20A 40V-DC Module Terminal Block

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

8768650000 information

Weidmüller 8768650000 technical specifications, attributes, parameters and parts with similar specifications to Weidmüller 8768650000.

Type
Parameter

Factory Lead Time
9 Weeks

Mounting Type
Terminal Block

Package / Case
Module

Weight
400g

Packaging
Bulk

Published
2010

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Depth
100mm

Approval Agency
CE, cULus, cURus

Element Configuration
Common Cathode

Diode Type
Silicon Carbide Schottky

Output Current
20A

Output Power
960W

Operating Temperature - Junction
-10°C~55°C

Max Reverse Voltage (DC)
40V

Average Rectified Current
20A

Diode Configuration
1 Pair Common Cathode

Height
125mm

Length
110mm

Width
55.5mm

REACH SVHC
No SVHC

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for Weidmüller 8768650000.

Datasheets:

weidmuller-8768650000-datasheets-8669.pdf

weidmuller-8768650000-datasheets-8670.pdf

8768650000 Overview

8768650000 Features

8768650000 Applications

There are a lot of Weidmüller
8768650000 applications of rectifier diode array.

Rectifier for drives applications
Crowbar applications
Rectifiers for UBS
Battery chargers
Rectifiers in switch mode power supplies (SMPS)
Free wheeling diode in low voltage converters
General Rectification
