842023BGLF information

Renesas 842023BGLF technical specifications, attributes, parameters and parts with similar specifications to Renesas 842023BGLF.

  • Type
  • Parameter
  • Contact Plating
  • Tin
  • Mount
  • Surface Mount
  • Package / Case
  • TSSOP
  • Number of Pins
  • 8
  • Published
  • 2007
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 8
  • ECCN Code
  • EAR99
  • Max Operating Temperature
  • 70°C
  • Min Operating Temperature
  • 0°C
  • Additional Feature
  • CAN ALSO OPERATES WITH 2.375V TO 2.625V SUPPLY
  • Subcategory
  • Clock Generators
  • Technology
  • CMOS
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.65mm
  • Time@Peak Reflow Temperature-Max (s)
  • 30
  • Pin Count
  • 8
  • Qualification Status
  • Not Qualified
  • Temperature Grade
  • COMMERCIAL
  • Number of Circuits
  • 1
  • Max Supply Voltage
  • 3.465V
  • Min Supply Voltage
  • 2.265V
  • Nominal Supply Current
  • 84mA
  • uPs/uCs/Peripheral ICs Type
  • CLOCK GENERATOR, OTHER
  • Frequency (Max)
  • 340MHz
  • Input
  • Crystal
  • Primary Clock/Crystal Frequency-Nom
  • 25MHz
  • PLL
  • Yes
  • Length
  • 3.1mm
  • Width
  • 4.4mm
  • Thickness
  • 1mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for Renesas 842023BGLF.

Datasheets:

842023BGLF Overview


In a TSSOP-shaped case, it comes. As far as terminations are concerned, there are 8. Voltage is provided by the part at 3.3V. Running 260 utilizes this part's peak reflow temperature. There are CLOCK GENERATOR, OTHER user processors, user controllers, or peripheral integrated circuits on this device. On the device, there are 1. For normaloperation, 340MHz is the maximum frequency. With this device, it is also possible to find CAN ALSO OPERATES WITH 2.375V TO 2.625V SUPPLY. A total of 2007 parts have been published. Ideally, it should be mounted with Surface Mount. Devices with 8 pins are designed. A total of 8 pins are included. Temperatures below 0°C are not acceptable for this device. Temperatures below 70°C are recommended for operation. Clock Generators is the family name of the device. Voltage 3.465V is the supply voltage for this part. Circuits application is important to maintain a voltage on the device that is greater than 2.265V.

842023BGLF Features


Peak Reflow Temperature (Cel): 260
uPs/uCs/Peripheral ICs Type of CLOCK GENERATOR, OTHER
Include 1 Circuits
with 8 Pins


842023BGLF Applications


There are a lot of Integrated Device Technology (IDT)
842023BGLF application specific timer applications.


  • Wireless Access Point
  • Routers
  • Ethernet switch/router
  • PCI Express 2.0/3.0
  • Broadcast video/audio timing
  • Processor and FPGA clocking
  • Any-frequency clock conversion
  • MSAN/DSLAM/PON
  • Fibre Channel, SAN
  • Telecom line cards

User Guide
