Renesas 841602AGILF

Manufacturer No:

841602AGILF

Manufacturer:

Renesas

Package:

TSSOP

Description:

3.3V 125MHz Clock Generators 28 Pins TSSOP 28 Terminals Bulk

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

841602AGILF information

Renesas 841602AGILF technical specifications, attributes, parameters and parts with similar specifications to Renesas 841602AGILF.

Type
Parameter

Factory Lead Time
7 Weeks

Mount
Surface Mount

Package / Case
TSSOP

Number of Pins
28

Packaging
Bulk

Published
2005

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
28

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
85°C

Min Operating Temperature
-40°C

Subcategory
Clock Generators

Technology
CMOS

Terminal Position
DUAL

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
260

Supply Voltage
3.3V

Terminal Pitch
0.65mm

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
28

Temperature Grade
INDUSTRIAL

Number of Circuits
1

Max Supply Voltage
3.465V

Min Supply Voltage
3.015V

uPs/uCs/Peripheral ICs Type
CLOCK GENERATOR, OTHER

Supply Current-Max
87mA

Frequency (Max)
125MHz

Input
Crystal

Primary Clock/Crystal Frequency-Nom
25MHz

Length
7.7mm

Width
6.1mm

Thickness
1mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas 841602AGILF.

Datasheets:

integrateddevicetechnology-841602agilf-datasheets-1930.pdf

841602AGILF Overview

Bulk-method packaging is used for clock ICs. The TSSOP package contains this clock generator. This clock generator ic can sustain a maximum temperature of 260 during reflowing. It contains 28 terminations that can be found in frequency synthesizer. This electronic frequency generator requires a voltage of 3.3V. The input of this clock generator is designed to be Crystal. To access the full performance of the electronic component, 1 circuits are implemented. There is a maximum frequency of 125MHz Max with this clock-based frequency generator. This time clock generator integrates CLOCK GENERATOR, OTHER uPs, uCs, and peripheral ICs. The clock-generating IC is a 28-bit device designed specifically for microprocessors. It is possible to connect to the frequency generators via 28 pins. Despite its low-temperature operation, this clock generator ic is capable of -40°C operations. Despite its attenuated performance, this frequency synthesizer can last at 85°C. There is a maximum supply voltage of 3.3V that clock generator can handle. This clock generator can be classified as a kind of Clock Generators in general. It is unacceptable to supply this clock PLL with a voltage higher than 3.465V. There is a maximum supply voltage of 3.015V for this RF synthesizer. It is possible for an element to be thermally destroyed if clock PLL?s supply current (greater than 87mA) is excessive.

841602AGILF Features

Available in the TSSOP
Supply voltage of 3.3V
Operating supply voltage of 3.3V

841602AGILF Applications

There are a lot of Integrated Device Technology (IDT)
841602AGILF Clock Generators applications.

Automatic test equipment
Wide area power system
Digital circuits
Wireless base station for LTE, LTE-advanced
Picocells, femtocells and small cells
Sampling clocks for ADC and DAC
1 Gigabit Ethernet
10 Gigabit Ethernet
FPGA and processor clocks
Line cards used in telephone exchange
