Renesas 82P2282PF
Renesas 82P2282PF

Renesas 82P2282PF

Manufacturer No:

82P2282PF

Manufacturer:

Renesas

Package:

TQFP

Description:

100 Terminations 100 Pin Telecom device 1 Functions Min 1.68V V Max 3.6V V

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

82P2282PF information

Renesas 82P2282PF technical specifications, attributes, parameters and parts with similar specifications to Renesas 82P2282PF.

  • Type
  • Parameter
  • Factory Lead Time
  • 17 Weeks
  • Mount
  • Surface Mount
  • Package / Case
  • TQFP
  • Number of Pins
  • 100
  • Published
  • 2009
  • JESD-609 Code
  • e0
  • Pbfree Code
  • no
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 100
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Tin/Lead (Sn85Pb15)
  • Max Operating Temperature
  • 85°C
  • Min Operating Temperature
  • -40°C
  • Subcategory
  • Other Telecom ICs
  • Technology
  • BIPOLAR
  • Terminal Position
  • QUAD
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 240
  • Number of Functions
  • 1
  • Supply Voltage
  • 1.8V
  • Terminal Pitch
  • 0.65mm
  • Time@Peak Reflow Temperature-Max (s)
  • 20
  • Pin Count
  • 100
  • Power Supplies
  • 3.3V
  • Interface
  • SPI
  • Max Supply Voltage
  • 3.6V
  • Min Supply Voltage
  • 1.68V
  • Nominal Supply Current
  • 20mA
  • Logic Function
  • Transceiver
  • Data Rate
  • 2.048 Mbps
  • Number of Transceivers
  • 2
  • Carrier Type
  • T-1(DS1)
  • Height Seated (Max)
  • 1.6mm
  • Width
  • 14mm
  • Radiation Hardening
  • No
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for Renesas 82P2282PF.

Datasheets:

82P2282PF Overview


A TQFP package is used to reduce board space requirements.The mounting is in the way of Surface Mount.Configuration of this telecom circuit has 100 terminations.There is a voltage supply called 1.8V that it uses.The telecom interface has 100 pins.The telecommunications device is part of the Other Telecom ICs subcategory.Temperature should be set at the minimum value of -40°C to ensure normal operation.85°C is set to the maximum value to ensure normal operation.While designing, telecommunications device has 1 functions configured.A minimum voltage of 1.68V should be supplied.A lower voltage than 3.6V should be supplied.Its pin configuration is determined by 100 telecom product pins.Integrated wtelecommunication toolsh 2 transceivers, telecommunication tools provides wireless communication.

82P2282PF Features


Available in the TQFP package
2 transceivers


82P2282PF Applications


There are a lot of Integrated Device Technology (IDT)
82P2282PF Telecom applications.


  • Fractional T1/E1/J1
  • BITS Timing
  • Digital Access Cross-connect System (DACs)
  • Digital Cross-connect Systems (DCS)
  • Frame Relay Switches and Access Devices (FRADS)
  • ISDN Primary Rate Interfaces (PRA)
  • PBXs channel bank
  • PCM channel bank
  • T3 channelized access concentrators
  • M13 MUX
