8209-7003 information

3M 8209-7003 technical specifications, attributes, parameters and parts with similar specifications to 3M 8209-7003.

  • Type
  • Parameter
  • Factory Lead Time
  • 9 Weeks
  • Contact Material
  • Copper Alloy
  • Contact Plating
  • Gold
  • Mount
  • Cable, Panel
  • Mounting Type
  • Panel Mount
  • Dielectric Material
  • Polybutylene Terephthalate (PBT), Polyester, Glass Filled
  • Housing Material
  • Polybutylene
  • Shell Material, Finish
  • Steel, Tin Plated
  • Operating Temperature
  • -55°C~105°C
  • Packaging
  • Bulk
  • Series
  • 8200
  • Published
  • 2009
  • Feature
  • Grounding Indents
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 9
  • Termination
  • IDC, Ribbon Cable
  • Connector Type
  • Plug, Male Pins
  • Number of Positions
  • 9
  • Max Operating Temperature
  • 105°C
  • Min Operating Temperature
  • -55°C
  • Color
  • Gray
  • Number of Rows
  • 2
  • Gender
  • Male
  • Current Rating (Amps)
  • 1A
  • Pitch
  • 2.76mm
  • Orientation
  • Right Angle
  • Current Rating
  • 1A
  • Contact Finish
  • Gold
  • Number of Contacts
  • 9
  • Housing Color
  • Grey
  • Flange Feature
  • Housing/Shell (4-40)
  • Max Current Rating
  • 1A
  • Plating
  • Steel, Tin
  • Connector Style
  • D-Sub
  • Number of Ports
  • 1
  • Shell Size, Connector Layout
  • 1 DE E
  • Contact Finish Thickness
  • 30.0?in 0.76?m
  • Material Flammability Rating
  • UL94 V-0
  • RoHS Status
  • RoHS Compliant
  • Flammability Rating
  • UL94 V-0
  • Lead Free
  • Lead Free
