Renesas 79RC32K438-233BBG

Manufacturer No:

79RC32K438-233BBG

Manufacturer:

Renesas

Package:

BGA

Description:

32-bit Microprocessor 416-Pin 233MHz 1.2V BGA

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

79RC32K438-233BBG information

Renesas 79RC32K438-233BBG technical specifications, attributes, parameters and parts with similar specifications to Renesas 79RC32K438-233BBG.

Type
Parameter

Mount
Surface Mount

Package / Case
BGA

Number of Pins
416

Published
1999

JESD-609 Code
e1

Pbfree Code
yes

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
416

Terminal Finish
TIN SILVER COPPER

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Technology
CMOS

Terminal Position
BOTTOM

Terminal Form
BALL

Peak Reflow Temperature (Cel)
260

Supply Voltage
1.2V

Frequency
233MHz

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
416

Operating Supply Voltage
1.2V

Temperature Grade
INDUSTRIAL

Max Supply Voltage
1.3V

Min Supply Voltage
1.1V

Bit Size
32

Frequency (Max)
233MHz

Data Bus Width
32b

Boundary Scan
YES

Low Power Mode
NO

Format
FIXED POINT

Integrated Cache
YES

Number of Cores
1

Length
27mm

Height Seated (Max)
2.44mm

Width
27mm

Thickness
2.23mm

Radiation Hardening
No

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas 79RC32K438-233BBG.

Datasheets:

integrateddevicetechnology-79rc32k438233bbg-datasheets-5993.pdf

79RC32K438-233BBG Overview

The microprocessor is conveniently packaged in BGA, making it easy to ship internationally. This is a MICROPROCESSOR, RISC for the uPs/uCs/Peripheral ICs type. Total terminations are 416. In the case of a 1.2V voltage supply, the embedded microprocessor should be turned on and run. A 32-Bit architecture is used. CPUs operate at 233MHz Hz. For functions of 416 pins, please refer to the datasheets. Data can be transferred over 32b bandwidths. Temperatures above 70°C are not suitable for operating the microprocessor. The CPU microprocessor body is injected with 416 pins. A CPU with 1 cores. Many applications use this CPU with Surface Mount mounted. 233MHz is expected to be the top frequency of the CPU. From 1.2V, the micro processor can be used. The embedded microprocessor should not be supplied with a voltage higher than 1.3V. 1.1V should be the lowest voltage fed to the CPU microprocessor.

79RC32K438-233BBG Features

32-Bit Structure
32b-Bit Data Bus Width
1-Core CPU

79RC32K438-233BBG Applications

There are a lot of Integrated Device Technology (IDT)
79RC32K438-233BBG Microprocessor applications.

Automatic control
Equipment control
Instrument control
Consumer electronics products
Toys
Robots
Radio
Television
Heater/Fan
Calculator
