Tusonix a Subsidiary of CTS Electronic Components 7604-501NLF

Manufacturer No:

7604-501NLF

Manufacturer:

Tusonix a Subsidiary of CTS Electronic Components

Package:

Description:

Tray 1 Rows Chassis, Panel Barrier Block PC Pin 0.437 11.10mm 2 Wall (Dual) 4 Circuits Polybutylene Terephthalate (PBT)

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

7604-501NLF information

Tusonix a Subsidiary of CTS Electronic Components 7604-501NLF technical specifications, attributes, parameters and parts with similar specifications to Tusonix a Subsidiary of CTS Electronic Components 7604-501NLF.

Type
Parameter

Mount
Chassis, Panel

Mounting Type
Chassis, Panel

Housing Material
Thermoplastic

Material - Insulation
Polybutylene Terephthalate (PBT)

Operating Temperature
-40°C~125°C

Packaging
Tray

Published
2009

Feature
Filter 2000pF, Flange

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Termination
Screw

ECCN Code
EAR99

Number of Rows
1

Voltage - Rated
250V

Pitch
0.437 11.10mm

Current Rating
20A

Insulation Resistance
10GOhm

Number of Circuits
4

Wire Gauge (Max)
12 AWG

Number of Decks
1

Terminal Block Type
Barrier Block

Bottom Termination
PC Pin

Barrier Type
2 Wall (Dual)

Number of Ways
4

Safety Approval
UL

Height
39.62mm

Length
65.79mm

Width
16.51mm

Material Flammability Rating
UL94 V-0

RoHS Status
RoHS Compliant

Flammability Rating
UL94 V-0

Download datasheets and manufacturer documentation for Tusonix a Subsidiary of CTS Electronic Components 7604-501NLF.

7604-501NLF Overview

There is a mounting type of Chassis, Panel for this device.It is necessary to use a Tray case for packaging the product.In many ways, its Filter 2000pF, Flange feature makes it more powerful.Chassis, Panel is used to mount the part.A total of 4 circuits are present in the part.In this case, the device operates at -40°C~125°C Operating Temperature.

7604-501NLF Features

7604-501NLF Applications

There are a lot of Tusonix a Subsidiary of CTS Electronic Components
7604-501NLF Terminal Blocks applications.

Transportation
Embedded systems
Datacom
Communication
Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
Telecommunications
