Renesas 74SSTV16859NLG8

Manufacturer No:

74SSTV16859NLG8

Manufacturer:

Renesas

Package:

Description:

13 Bit 2.5V Specialty Logic IC 56 Pin 0.5mm 2.5V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

74SSTV16859NLG8 information

Renesas 74SSTV16859NLG8 technical specifications, attributes, parameters and parts with similar specifications to Renesas 74SSTV16859NLG8.

Type
Parameter

Contact Plating
Tin

Mount
Surface Mount

Number of Pins
56

Packaging
Tape & Reel

Published
2007

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
3 (168 Hours)

Number of Terminations
56

ECCN Code
EAR99

Max Operating Temperature
85°C

Min Operating Temperature
0°C

Subcategory
Other Logic ICs

Terminal Position
QUAD

Terminal Form
NO LEAD

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
2.5V

Terminal Pitch
0.5mm

Frequency
200MHz

Time@Peak Reflow Temperature-Max (s)
30

Pin Count
56

Number of Outputs
26

Number of Elements
1

Polarity
Non-Inverting

Power Supplies
2.5V

Temperature Grade
INDUSTRIAL

Max Supply Voltage
2.7V

Min Supply Voltage
2.3V

Number of Bits
13

Propagation Delay
2.8 ns

Frequency (Max)
200MHz

Family
SSTV

Logic Function
Buffer

Logic IC Type
D FLIP-FLOP

High Level Output Current
-20mA

Low Level Output Current
20mA

Clock Edge Trigger Type
Positive Edge

Length
8mm

Width
8mm

Thickness
850?m

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas 74SSTV16859NLG8.

74SSTV16859NLG8 Overview

Tape & Reel is employed as a way of packaging.The voltage of 2.5V is supplied to make sure that the device is able to operate normally.The memory features a size of 13 bits to store information.The number of all component pins adds up to 56.Signals are prevented from reflecting off the end of the transmission line through 56 terminations.It is mounted in the way of Surface Mount.There are 56 pins to form parts of its construction.Normal use can be kept when the minimum supply voltage is kept at 2.3V.Normal use can be kept when the maximum supply voltage is kept at 2.7V.It can be included into the subcategory of Other Logic ICs.The power supplies of 2.5V should be maintained for convenient use.The electronic part belongs to the family of SSTV that is optimized for high quality and reliable performance.What is much essential is that its operating temperature should not exceed the maximum value of 85°C.What is much essential is that its operating temperature should not be lower than the minimum value of 0°C.It is composed of 1 elements.It operates with the frequency of 200MHz.D FLIP-FLOP is adopted as its logic IC type.26 outputs are equipped to form the basis of its configuration.
