NEXPERIA 74HCT393D

Manufacturer No:

74HCT393D

Manufacturer:

NEXPERIA

Package:

SOP-14

Description:

Description: Binary Counter, HCT Series, Asynchronous, Negative Edge Triggered, 4-Bit, Up Direction, CMOS, PDSO14

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

74HCT393D information

NEXPERIA 74HCT393D technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA 74HCT393D.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
NEXPERIA

Package Description
SOP-14

Reach Compliance Code
compliant

HTS Code
8542.39.00.01

Date Of Intro
1991-01-01

Samacsys Manufacturer
Nexperia

Count Direction
UP

Family
HCT

JESD-30 Code
R-PDSO-G14

JESD-609 Code
e4

Length
8.65 mm

Load Capacitance (CL)
50 pF

Load/Preset Input
NO

Logic IC Type
BINARY COUNTER

Mode of Operation
ASYNCHRONOUS

Moisture Sensitivity Level
1

Number of Bits
4

Number of Functions
2

Number of Terminals
14

Operating Temperature-Max
125 °C

Operating Temperature-Min
-40 °C

Package Body Material
PLASTIC/EPOXY

Package Shape
RECTANGULAR

Package Style
SMALL OUTLINE

Peak Reflow Temperature (Cel)
260

Propagation Delay (tpd)
38 ns

Qualification Status
Not Qualified

Seated Height-Max
1.75 mm

Supply Voltage-Max (Vsup)
5.5 V

Supply Voltage-Min (Vsup)
4.5 V

Supply Voltage-Nom (Vsup)
5 V

Surface Mount
YES

Technology
CMOS

Temperature Grade
AUTOMOTIVE

Terminal Finish
NICKEL PALLADIUM GOLD

Terminal Form
GULL WING

Terminal Pitch
1.27 mm

Terminal Position
DUAL

Time@Peak Reflow Temperature-Max (s)
30

Trigger Type
NEGATIVE EDGE

Width
3.9 mm

fmax-Min
18 MHz

Download datasheets and manufacturer documentation for NEXPERIA 74HCT393D.

Datasheets:

NEXP-S-A0013796743-1.pdf

74HCT393D Overview

It is a device supplied in the SO package. 14 terminations are used for its configuration. The supply voltage of 5V enables it operate in a fully flexible way. There are 14 pins going on to connect other parts in the circuit. It emerges as a member of HCT family. The are 4 bits information in the device. This device is manufactured in the temperature grade of AUTOMOTIVE. It operates at the maximum temperature of 125°C for extended periods of time with acceptable stability of its electrical characteristics. It is designed to operate over a specified temperature range with lower limit generally set at -40°C. It operates with the frequency of 53MHz. The maximum voltage available for the device reaches 5.5V. The minimum voltage available for the device is as low as 4.5V. BINARY COUNTER is the logic IC type it uses.

74HCT393D Features

Embedded in the SO package
Frequency of 53MHz
BINARY COUNTER as logic IC type

74HCT393D Applications

There are a lot of Nexperia
74HCT393D Counters & Dividers applications.

Control counters
Timers
Frequency dividers
Time-delay circuits
Analog multiplexing and demultiplexing
Digital multiplexing and demultiplexing
Signal gating
Frequency dividing circuits
Time delay circuits
Communications Digital Frequency Synthesizers;
