NEXPERIA 74HC4060D

Manufacturer No:

74HC4060D

Manufacturer:

NEXPERIA

Package:

Description:

Binary Counter

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

74HC4060D information

NEXPERIA 74HC4060D technical specifications, attributes, parameters and parts with similar specifications to NEXPERIA 74HC4060D.

Type
Parameter

RoHS Status
RoHS Compliant

Part Life Cycle Code
Active

Ihs Manufacturer
NEXPERIA

Reach Compliance Code
compliant

ECCN Code
EAR99

HTS Code
8542.39.00.01

Date Of Intro
1990-12-01

Samacsys Manufacturer
Nexperia

Additional Feature
OUTPUTS FROM 10 STAGES AVAILABLE

Count Direction
UP

Family
HC/UH

JESD-30 Code
R-PDSO-G16

JESD-609 Code
e4

Length
9.9 mm

Load/Preset Input
YES

Logic IC Type
BINARY COUNTER

Mode of Operation
ASYNCHRONOUS

Moisture Sensitivity Level
1

Number of Bits
14

Number of Functions
1

Number of Terminals
16

Operating Temperature-Max
125 °C

Operating Temperature-Min
-40 °C

Package Body Material
PLASTIC/EPOXY

Package Shape
RECTANGULAR

Package Style
SMALL OUTLINE

Peak Reflow Temperature (Cel)
260

Propagation Delay (tpd)
450 ns

Seated Height-Max
1.75 mm

Supply Voltage-Max (Vsup)
6 V

Supply Voltage-Min (Vsup)
2 V

Supply Voltage-Nom (Vsup)
5 V

Surface Mount
YES

Technology
CMOS

Temperature Grade
AUTOMOTIVE

Terminal Finish
NICKEL PALLADIUM GOLD

Terminal Form
GULL WING

Terminal Pitch
1.27 mm

Terminal Position
DUAL

Time@Peak Reflow Temperature-Max (s)
30

Trigger Type
POSITIVE EDGE

Width
3.9 mm

fmax-Min
24 MHz

Download datasheets and manufacturer documentation for NEXPERIA 74HC4060D.

Datasheets:

NEXP-S-A0013451682-1.pdf

74HC4060D Overview

This device is supplied in the SO package. The 1elements are connected by wires. In the circuit, there are 16pins that connect other components. It is mounted in the manner of [0]. The device contains 14bits of information. For the device to operate, a voltage supply of 5Vis required. Despite operating at 125°Cfor extended periods, its electrical characteristics remain stable. This device is designed to operate within a specified temperature range with a lower limit generally set at -40°C. The frequency of the device is 95MHz. There is a maximum voltage available for the device of 6V. It is possible for the device to operate at a voltage as low as 2V.

74HC4060D Features

Embedded in the SO package
Operating supply voltage of 5V
Frequency of 95MHz

74HC4060D Applications

There are a lot of Nexperia
74HC4060D Counters & Dividers applications.

Timers
Frequency dividers
Time-delay circuits
Analog multiplexing and demultiplexing
Digital multiplexing and demultiplexing
Signal gating
Frequency dividing circuits
Time delay circuits
Communications Digital Frequency Synthesizers;
VHF, UHF, FM, AM, etc.
