Renesas 72401L25SO

Manufacturer No:

72401L25SO

Manufacturer:

Renesas

Package:

SOIC

Description:

16 Terminations 5V 16 Pin FIFO memory IC 34 ns Min 4.5V V Max 5.5V V

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

72401L25SO information

Renesas 72401L25SO technical specifications, attributes, parameters and parts with similar specifications to Renesas 72401L25SO.

Type
Parameter

Contact Plating
Lead, Tin

Mount
Surface Mount

Package / Case
SOIC

Number of Pins
16

Published
2009

JESD-609 Code
e0

Pbfree Code
no

Part Status
Discontinued

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
16

ECCN Code
EAR99

Terminal Finish
Tin/Lead (Sn85Pb15)

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Additional Feature
FALL THRU 40NS

HTS Code
8542.32.00.71

Subcategory
FIFOs

Technology
CMOS

Terminal Form
GULL WING

Peak Reflow Temperature (Cel)
225

Number of Functions
1

Supply Voltage
5V

Terminal Pitch
1.27mm

Pin Count
16

Power Supplies
5V

Temperature Grade
COMMERCIAL

Max Supply Voltage
5.5V

Min Supply Voltage
4.5V

Element Configuration
Dual

Nominal Supply Current
35mA

Max Supply Current
35mA

Clock Frequency
25MHz

Access Time
34 ns

Organization
64X4

Density
256 b

Parallel/Serial
PARALLEL

Sync/Async
Asynchronous

Word Size
4b

Memory IC Type
OTHER FIFO

Bus Directional
Unidirectional

Retransmit Capability
No

Output Enable
NO

Cycle Time
40 ns

Length
10.4mm

Height Seated (Max)
2.65mm

Width
7.6mm

Thickness
2.34mm

Download datasheets and manufacturer documentation for Renesas 72401L25SO.

Datasheets:

integrateddevicetechnology-72401l25so-datasheets-5817.pdf

72401L25SO Overview

The SOIC package contains FIFO memory chip.It is recommended that memory IC be mounted in the Surface Mount direction.When the supply voltage is 5V there is the possibility of high efficiency.As a result of this, FIFO means contains 16 terminations.As far as the operation pins are concerned, they are 16 pins.FIFO requires a minimum of 35mA current to operate.When setting the supply voltage to 5V , you will achieve FIFO's maximum efficiency.It operates at 0°C degrees Celsius to ensure reliability.By using a memory logic's maximum operating temperature of 70°C degrees Celsius, stable operation can be achieved.It is contained within FIFOs .ICs of type OTHER FIFO are used in the FIFO memory chip.It is possible to operate the FIFO memory chip at very low supply voltages, such as 4.5V volts.This FIFO memory chip can handle maximum supply voltages of 5.5V volts.This FIFO memory IC is equipped with 16 pins in total.It is normal for the component to own 5V power supplies.Additionally, this FIFO memory is capable of generating FALL THRU 40NS as well.FIFO memory ICs run at a frequency of 25MHz .

72401L25SO Features

FIFOs category
Clock frequency of 25MHz

72401L25SO Applications

There are a lot of Integrated Device Technology (IDT)
72401L25SO FIFOs Memory applications.

Video
Data
Telecommunication
Network switching/routing
Computer networks
Network bridges
Switches
Routers
Cameras
Multimedia

User Guide
