Renesas 70121L25JG8

Manufacturer No:

70121L25JG8

Manufacturer:

Renesas

Package:

PLCC

Description:

5V V 52 Pin Memory IC 18 kb kb 19mm mm

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

70121L25JG8 information

Renesas 70121L25JG8 technical specifications, attributes, parameters and parts with similar specifications to Renesas 70121L25JG8.

Type
Parameter

Factory Lead Time
7 Weeks

Package / Case
PLCC

Surface Mount
YES

Number of Pins
52

Published
2008

JESD-609 Code
e3

Pbfree Code
yes

Part Status
Active

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Number of Terminations
52

ECCN Code
EAR99

Terminal Finish
Matte Tin (Sn) - annealed

Max Operating Temperature
70°C

Min Operating Temperature
0°C

Additional Feature
INTERRUPT FLAG; AUTOMATIC POWER-DOWN; BATTERY BACKUP

Subcategory
SRAMs

Technology
CMOS

Terminal Position
QUAD

Terminal Form
J BEND

Peak Reflow Temperature (Cel)
260

Number of Functions
1

Supply Voltage
5V

Time@Peak Reflow Temperature-Max (s)
NOT SPECIFIED

Pin Count
52

Operating Supply Voltage
5V

Power Supplies
5V

Temperature Grade
COMMERCIAL

Interface
Parallel

Max Supply Voltage
5.5V

Min Supply Voltage
4.5V

Memory Size
2.3kB

Number of Ports
2

Memory Type
RAM, SDR, SRAM

Operating Mode
ASYNCHRONOUS

Access Time
25 ns

Output Characteristics
3-STATE

Address Bus Width
22b

Density
18 kb

Standby Current-Max
0.005A

I/O Type
COMMON

Standby Voltage-Min
2V

Length
19mm

Height Seated (Max)
4.57mm

Width
19mm

Thickness
3.63mm

RoHS Status
RoHS Compliant

Lead Free
Lead Free

Download datasheets and manufacturer documentation for Renesas 70121L25JG8.

Datasheets:

integrateddevicetechnology-70121l25jg8-datasheets-6771.pdf

70121L25JG8 Overview

A RAM, SDR, SRAM-type memory can be classified as the memory type of this device. Embedded in the PLCC case, memory ics is a single file. On the chip, there is an 2.3kB memory, which is the size of the chip's memory. A total of 52 terminations have been planted on the chip. The comprehensive working procedure of this part involves 1 functions. In order to power this memory device, 5V will be necessary. A 52-pin package containing this memory device is used to house this device. The memory device in question has 52 pins, thus indicating that it has 52 memory locations that can be accessed. There is a note indicating that this memory chip operates at an 5V volt supply voltage. This chip features all the merits of a conventional chip, but it also features INTERRUPT FLAG; AUTOMATIC POWER-DOWN; BATTERY BACKUP to improve system performance. 2 ports allow read/write access to one memory address in this chip. As for power supplies, this memory chip requires just 5V . As part of the design, the I/O port addresses are mapped into the memory using an COMMON-bit number. There must not be a minimum operating temperature of less than 0°C for this device. A temperature of no more than 70°C centigrade is recommended for the component to be operated, otherwise, damage might be inflicted on the component. Usually, this memory ics falls under the SRAMs component category. Ideally, this part should be supplied with a voltage of at least 4.5V. An operating voltage of no more than 5.5V is required.

70121L25JG8 Features

Package / Case: PLCC
52 Pins
Operating Supply Voltage:5V
Additional Feature:INTERRUPT FLAG; AUTOMATIC POWER-DOWN; BATTERY BACKUP
I/O Type: COMMON
