rubycon 63PZA27M8X12.5

Manufacturer No:

63PZA27M8X12.5

Manufacturer:

rubycon

Package:

Radial, Can

Description:

27?F ±20% Radial, Can 0.492 12.50mm Bulk 33mOhm PZA Through Hole Polymer Automotive

Quantity:

Delivery:

Payment:

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

63PZA27M8X12.5 information

rubycon 63PZA27M8X12.5 technical specifications, attributes, parameters and parts with similar specifications to rubycon 63PZA27M8X12.5.

Type
Parameter

Mount
Through Hole

Mounting Type
Through Hole

Package / Case
Radial, Can

Operating Temperature
-55°C~105°C

Packaging
Bulk

Series
PZA

Size / Dimension
0.315Dia 8.00mm

Tolerance
±20%

Part Status
Obsolete

Moisture Sensitivity Level (MSL)
1 (Unlimited)

Type
Polymer

Applications
Automotive

Voltage - Rated
63V

Capacitance
27?F

Lead Pitch
3.5052mm

ESR (Equivalent Series Resistance)
33mOhm

Lead Spacing
0.138 3.50mm

Lifetime @ Temp
3000 Hrs @ 105°C

Ripple Current
2.1A

Life (Hours)
3000 hours

Ripple Current @ Low Frequency
105mA @ 120Hz

Ripple Current @ High Frequency
2.1A @ 100kHz

Height Seated (Max)
0.492 12.50mm

RoHS Status
RoHS Compliant

Download datasheets and manufacturer documentation for rubycon 63PZA27M8X12.5.

Datasheets:

rubycon-50pza12m63x8-datasheets-7802.pdf

63PZA27M8X12.5 Overview

It is necessary to have a ripple current at high frequency of 2.1A @ 100kHz to power systems.The device has an ESR of 33mOhm.105mA @ 120Hz needs a ripple current @ Low Frequency to function properly.A stable operating temperature is -55°C~105°C.

63PZA27M8X12.5 Features

2.1A @ 100kHz ripple current on a high frequency
a 33mOhm in ESR (Equivalent Series Resistance) in this electrical device
an operating temperature of -55°C~105°C

63PZA27M8X12.5 Applications

There are a lot of Rubycon
63PZA27M8X12.5 applications of aluminum polymer capacitors.

LED driver power supplies
Phone chargers
Motherboards
Servers and adapters (laptop power supplies)
Medical equipment
Switching Power Supply and DC/DC Converter.
Buck up Power Supplies of CPU(VRM etc.)
Miniature high Power Supply.
