INTEL 5M40ZE64C4N
INTEL 5M40ZE64C4N

INTEL 5M40ZE64C4N

Manufacturer No:

5M40ZE64C4N

Manufacturer:

INTEL

Package:

64-TQFP Exposed Pad

Description:

0.4mm PMIC MAX® V Series 5M40Z 1.8V 64-TQFP Exposed Pad

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

5M40ZE64C4N information

INTEL 5M40ZE64C4N technical specifications, attributes, parameters and parts with similar specifications to INTEL 5M40ZE64C4N.

  • Type
  • Parameter
  • Factory Lead Time
  • 8 Weeks
  • Mounting Type
  • Surface Mount
  • Package / Case
  • 64-TQFP Exposed Pad
  • Surface Mount
  • YES
  • Operating Temperature
  • 0°C~85°C TJ
  • Packaging
  • Tray
  • Series
  • MAX® V
  • Published
  • 2003
  • JESD-609 Code
  • e3
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 3 (168 Hours)
  • Number of Terminations
  • 64
  • ECCN Code
  • EAR99
  • Terminal Finish
  • MATTE TIN
  • Terminal Position
  • QUAD
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • NOT SPECIFIED
  • Supply Voltage
  • 1.8V
  • Terminal Pitch
  • 0.4mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Base Part Number
  • 5M40Z
  • JESD-30 Code
  • S-PQFP-G64
  • Qualification Status
  • Not Qualified
  • Supply Voltage-Max (Vsup)
  • 1.89V
  • Programmable Type
  • In System Programmable
  • Number of I/O
  • 54
  • Clock Frequency
  • 184.1MHz
  • Propagation Delay
  • 7.9 ns
  • Output Function
  • MACROCELL
  • Number of Macro Cells
  • 32
  • Voltage Supply - Internal
  • 1.71V~1.89V
  • Delay Time tpd(1) Max
  • 7.5ns
  • Number of Logic Elements/Blocks
  • 40
  • Length
  • 7mm
  • Height Seated (Max)
  • 1.2mm
  • Width
  • 7mm
  • RoHS Status
  • RoHS Compliant

Download datasheets and manufacturer documentation for INTEL 5M40ZE64C4N.

Datasheets:

PCN Packaging:

5M40ZE64C4N Overview


There are 32 macro cells. A macro cell is a cell in a mobile phone network that provides radio coverage through the use of a high-power cell site (tower, antenna or mast).There is a 64-TQFP Exposed Pad package containing it.The device has 54inputs and outputs.Devices are programmed with terminations of [0].QUADis the terminal position of this electrical part.An electrical supply voltage of 1.8V is used to power it.It is recommended to package the chip by Tray.During operation, the operating temperature is kept at 0°C~85°C TJ to ensure its reliability.It is recommended to mount the chip by Surface Mount.The MAX? Vseries comprises this type of FPGA.The 5M40Zshows its related parts.There are 40 logic elements/blocks.There is a maximum supply voltage (Vsup) of 1.89V.There should be a higher supply voltage (Vsup) than 1.71V.It should not exceed 184.1MHzin terms of clockfrequency.

5M40ZE64C4N Features


64-TQFP Exposed Pad package
54 I/Os
The operating temperature of 0°C~85°C TJ

5M40ZE64C4N Applications


There are a lot of Intel 5M40ZE64C4N CPLDs applications.

  • Digital multiplexers

  • I/O expansion

  • I/O PORTS (MCU MODULE)

  • Power Meter SMPS

  • Protection relays

  • Timing control

  • Page register

  • Voltage level translation

  • Custom state machines

  • Wireless Infrastructure Base Band Unit and Remote Radio Unit
