Manufacturer No:

525-01RLF

Manufacturer:

Renesas

Package:

QSOP

Description:

3.3V 160MHz Clock Generators 28 Pins QSOP 28 Terminals

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

525-01RLF information

Renesas 525-01RLF technical specifications, attributes, parameters and parts with similar specifications to Renesas 525-01RLF.

  • Type
  • Parameter
  • Factory Lead Time
  • 7 Weeks
  • Mount
  • Surface Mount
  • Package / Case
  • QSOP
  • Number of Pins
  • 28
  • Published
  • 1999
  • JESD-609 Code
  • e3
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Number of Terminations
  • 28
  • ECCN Code
  • EAR99
  • Terminal Finish
  • Matte Tin (Sn) - annealed
  • Max Operating Temperature
  • 70°C
  • Min Operating Temperature
  • 0°C
  • Technology
  • CMOS
  • Terminal Position
  • DUAL
  • Terminal Form
  • GULL WING
  • Peak Reflow Temperature (Cel)
  • 260
  • Supply Voltage
  • 3.3V
  • Terminal Pitch
  • 0.635mm
  • Time@Peak Reflow Temperature-Max (s)
  • NOT SPECIFIED
  • Pin Count
  • 28
  • Number of Outputs
  • 2
  • Qualification Status
  • Not Qualified
  • Temperature Grade
  • COMMERCIAL
  • Number of Circuits
  • 1
  • Max Supply Voltage
  • 5.5V
  • Min Supply Voltage
  • 3V
  • Operating Supply Current
  • 8mA
  • Nominal Supply Current
  • 8mA
  • Frequency (Max)
  • 160MHz
  • Input
  • Clock
  • Primary Clock/Crystal Frequency-Nom
  • 50MHz
  • Length
  • 9.9mm
  • Width
  • 3.8mm
  • Thickness
  • 1.47mm
  • RoHS Status
  • RoHS Compliant
  • Lead Free
  • Lead Free

Download datasheets and manufacturer documentation for Renesas 525-01RLF.

Datasheets:

525-01RLF Overview


Embedded in the QSOP package is this Clock PLL. Frequency generator is capable of operating at a maximum temperature of 260 when reflowing. It contains a total of 28 terminations within RF synthesizer. This clock generator ic should receive a voltage of 3.3V. It is designed that the Clock PLL's input should be Clock. A total of 1 circuits are implemented to access the full performance of the electrical part. Using this clock-based frequency synthesizer, you can achieve a maximum frequency of 160MHz. In this IC, a 28-bit frequency generator is designed specifically for use in microprocessors. There are a number of 28 pins that are available on the clock generators. There are 0°C operations available on this frequency generator and it operates at low temperatures. It is possible for the clock generator ic to work at 70°C with a reduced performance. 2 signal outputs maximi2e the output frequency. There is no point in supplying this frequency generator with a voltage higher than 5.5V. PLLs have a minimum supply voltage limit of 3V. To fully perform its function, time clock generator requires a supply current of 8mA.

525-01RLF Features


Available in the QSOP
Supply voltage of 3.3V


525-01RLF Applications


There are a lot of Integrated Device Technology (IDT)
525-01RLF Clock Generators applications.


  • 1 Gigabit Ethernet
  • 10 Gigabit Ethernet
  • FPGA and processor clocks
  • Line cards used in telephone exchange
  • Fiber Channel
  • PCI express cards
  • Infotainment systems
  • Medical equipment
  • Multi-function printers
  • Media broadcast servers
