Manufacturer No:

5051102091

Manufacturer:

MOLEX

Package:

Description:

Easy-On FD19 505110 Series FFC, FPC Contacts, Bottom Tape & Reel (TR) 0.020 0.50mm Solder 20 Positions Surface Mount, Right Angle Gold -40°C~105°C 0.5A

Delivery:

DHL
DHL
DHL
DHL

Payment:

DHL
DHL
DHL
DHL
DHL
DHL

In Stock :Available

Price not displayed? Please send an RFQ, and we will respond immediately.

5051102091 information

MOLEX 5051102091 technical specifications, attributes, parameters and parts with similar specifications to MOLEX 5051102091.

  • Type
  • Parameter
  • Factory Lead Time
  • 17 Weeks
  • Contact Material
  • Phosphor Bronze
  • Mounting Type
  • Surface Mount, Right Angle
  • Housing Material
  • Liquid Crystal Polymer (LCP), Glass Filled
  • Mounting Option 1
  • LOCKING
  • Actuator Material
  • Polyamide (PA), Nylon, Glass Filled
  • Board Mounting Option
  • FITTING NAIL
  • Operating Temperature
  • -40°C~105°C
  • Packaging
  • Tape & Reel (TR)
  • Series
  • Easy-On FD19 505110
  • Published
  • 2015
  • JESD-609 Code
  • e4
  • Feature
  • Solder Retention, Zero Insertion Force (ZIF)
  • Pbfree Code
  • yes
  • Part Status
  • Active
  • Moisture Sensitivity Level (MSL)
  • 1 (Unlimited)
  • Termination
  • Solder
  • Connector Type
  • FFC/FPC CONNECTOR
  • Number of Positions
  • 20
  • Number of Rows
  • 1
  • Voltage - Rated
  • 50V
  • Subcategory
  • Headers and Edge Type Connectors
  • MIL Conformance
  • NO
  • DIN Conformance
  • NO
  • Filter Feature
  • NO
  • Mixed Contacts
  • NO
  • Option
  • GENERAL PURPOSE
  • Current Rating (Amps)
  • 0.5A
  • Pitch
  • 0.020 0.50mm
  • Total Number of Contacts
  • 20
  • Reference Standard
  • UL
  • Contact Finish
  • Gold
  • Reliability
  • COMMERCIAL
  • Body Length or Diameter
  • 0.578 inch
  • Number Of PCB Rows
  • 1
  • PCB Contact Pattern
  • RECTANGULAR
  • Body Breadth
  • 0.075 inch
  • Contact Gender
  • FEMALE
  • UL Flammability Code
  • 94V-0
  • Housing Color
  • Beige
  • Body Depth
  • 0.159 inch
  • Contact Style
  • BELLOWED TYPE
  • Contact Resistance
  • 40mOhm
  • Insulation Resistance
  • 50000000Ohm
  • Durability
  • 10 Cycles
  • Contact Pattern
  • RECTANGULAR
  • Insertion Force-Max
  • ZIF N

Download datasheets and manufacturer documentation for MOLEX 5051102091.

Datasheets:

PCN Design/Specification:

3D Drawings:

5051102091 Overview


Packaging is in the form of FFC/FPC CONNECTOR.The mounting type of the device is Surface Mount, Right Angle.A Tape & Reel (TR) case is used to package the product.A product of the Easy-On FD19 505110 Series, it belongs to the range of products of that series.A number of features make the Solder Retention, Zero Insertion Force (ZIF) feature more powerful.-40°C~105°C Operating Temperature is the default operating temperature for the device.
